FD2100L | Eaton 100A 2-Pole Molded Case Circuit Breaker, Series C, F-Frame
- Regular price
- $785.00
- Sale price
- $785.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: FD2100L
Description
The Eaton FD2100L is a molded case circuit breaker designed to provide dependable overcurrent protection in industrial and commercial power systems. This 2-pole breaker delivers consistent thermal-magnetic performance for 100-amp circuits at up to 600VAC or 250VDC. The FD2100L is well-suited for panelboards, switchboards, and equipment requiring robust interrupting capability.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton / Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | FD2100L |
| Subcategory | 2-Pole Circuit Breaker |
| Series | Series C |
| Frame Type | F-Frame |
| Amperage Rating | 100A |
| Voltage Rating | 600VAC, 250VDC |
| Poles | 2 |
| Phase | 1-Phase |
| Interrupting Rating | 35kAIC @ 480VAC; 65kAIC @ 240VAC |
| Protection Type | Thermal-Magnetic |
| Trip Functions | Long-Time & Instantaneous |
| Connection Type | Feed-Thru |
| Terminals | Line and Load Side Lug |
| Frequency | 50/60 Hz |
| Certification | UL Listed |
| Dimensions (H × W × D) | 6 in × 2.75 in × 3.38 in |
| Weight | 4.5 lb |
Information About FD2100L
The FD2100L is a Series C molded case circuit breaker built with an F-Frame housing and thermal-magnetic protection elements. It is compatible with standard feed-thru installations and supports single-phase applications requiring reliable long-time and instantaneous trip functions. The breaker is commonly used in power distribution systems where compact size and high interrupt ratings are required. Its UL-listed construction and lug-type terminals ensure secure integration into new or replacement installations.
Key Features:
- Series C Construction: Durable molded case design engineered for industrial and commercial environments.
- Thermal-Magnetic Protection: Provides long-time and instantaneous trip functions for overload and short-circuit protection.
- High Interrupt Rating: Rated 35kAIC at 480VAC and 65kAIC at 240VAC for dependable fault clearing.
- Feed-Thru Connection: Supports straightforward line-to-load wiring for panelboard and switchgear applications.
- F-Frame Design: Compact size compatible with standard Series C mounting footprints.
- UL Listed Certification: Meets industry safety requirements for approved electrical installations.
- Lug Terminations: Equipped with line and load side lugs for secure conductor attachment.
- Wide Voltage Range: Rated for 600VAC and 250VDC, suitable for AC or DC distribution systems.
The FD2100L delivers the reliability and precision required for molded case circuit protection in demanding electrical installations.
