FD2125L | Eaton 2-Pole 125A 600V Molded Case Circuit Breaker, 65kAIC Thermal Magnetic
- Regular price
- $1,485.00
- Sale price
- $1,485.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: FD2125L
Description
The Eaton FD2125L is a 2-pole thermal magnetic molded case circuit breaker designed for reliable protection of electrical systems in commercial and industrial environments. Rated for 125 amps and up to 600 VAC or 250 VDC, it ensures dependable overload and short-circuit protection. The FD2125L provides high interrupting capacities—65kA at 240V and 35kA at 480V—with a feed-thru connection and long-time/instantaneous trip functions.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton / Cutler-Hammer |
| Category | Circuit Protection |
| Part Number | FD2125L |
| Subcategory | Molded Case Circuit Breaker |
| Series | Series C |
| Frame Type | F Frame |
| Amperage Rating | 125 A |
| Voltage Rating | 600 VAC / 250 VDC |
| Number of Poles | 2 |
| Phase | Single Phase |
| Interrupting Rating | 65 kAIC @ 240 VAC; 35 kAIC @ 480 VAC; 18 kAIC @ 600 VAC |
| Trip Type | Thermal Magnetic (LI – Long-Time and Instantaneous) |
| Connection Type | Feed-Thru |
| Terminal Type | Line and Load Side Lugs |
| Frequency Rating | 50/60 Hz |
| Protection Type | Overload and Short Circuit |
| Certifications | UL Listed, CSA Approved |
| Temperature Rating | 40 °C |
| Dimensions (H × W × D) | 6 × 2.75 × 3.38 in |
| Weight | 4.5 lb |
Information About FD2125L
The FD2125L is part of Eaton’s Series C molded case circuit breaker family, known for its robust F-frame construction and broad voltage compatibility. It is engineered for single-phase applications and features both thermal and magnetic trip elements for precise fault response. The breaker is UL listed and CSA approved, ensuring compliance with industry safety standards for low-voltage power distribution. With line and load side lug terminals, it integrates seamlessly into panelboard and switchboard systems, providing secure, high-performance circuit protection.
Key Features:
- High Interrupting Capacity: Offers up to 65 kAIC at 240 VAC and 35 kAIC at 480 VAC for reliable fault clearing.
- Thermal Magnetic Protection: Combines long-time and instantaneous trip functions for comprehensive circuit safety.
- Wide Voltage Range: Operates at up to 600 VAC or 250 VDC for versatile use across system types.
- F-Frame Construction: Compact and durable housing for efficient installation and long service life.
- Feed-Thru Connection: Simplifies wiring for line and load integration in panel or enclosure applications.
- UL and CSA Certified: Meets UL 489 and CSA C22.2 No. 5 standards for performance and safety.
- Temperature Rated to 40°C: Ensures dependable operation in typical industrial environments.
- Bolt-On Design: Provides secure attachment and stable electrical connection in demanding applications.
The FD2125L delivers the reliability and precision required for safe and efficient electrical power distribution in industrial and commercial systems.
