Product Description P/N: FD3045L
Description
The FD3045L is a three-pole Eaton Series C complete molded case circuit breaker featuring an F-frame design. It operates at 600 Vac and 250 Vdc with a current rating of 45A. This breaker utilizes a fixed thermal and fixed magnetic trip type for reliable overcurrent protection. With an interrupt rating of 65 kAIC at 240 Vac and 35 kAIC at 480 Vac, it ensures robust performance in various electrical systems. The FD3045L supports both line and load connections and operates at frequencies of 50/60 Hz.
Technical Specifications
|
Product Name |
Eaton Series C complete molded case circuit breaker |
|
Catalog Number |
FD3045L |
|
UPC |
786679451748 |
|
Product Length/Depth |
3.38 in |
|
Product Height |
6 in |
|
Product Width |
4.13 in |
|
Product Weight |
4.5 lb |
|
Amperage Rating |
45 A |
|
Voltage Rating |
600 Vac, 250 Vdc |
|
Trip Type |
Fixed thermal, fixed magnetic |
|
Circuit Breaker Type |
FD |
|
Circuit Breaker Frame Type |
Complete breaker |
|
Series |
Series C |
|
Terminals |
Line and load |
|
Frame |
F |
|
Frequency Rating |
50/60 Hz |
|
Interrupt Rating |
35 kAIC at 480 Vac |
|
|
65 kAIC at 240 Vac |
|
Number of Poles |
Three-pole |
Information About FD3045L
The FD3045L is a molded case circuit breaker manufactured by Eaton, belonging to the Series C range. It features an F-frame design and is classified under the FD model. As a complete breaker, it integrates both fixed thermal and fixed magnetic trip mechanisms. This circuit breaker is configured as a three-pole unit, designed to handle a maximum current of 45A.
In terms of voltage compatibility, the FD3045L is rated for use with both alternating current (AC) and direct current (DC) systems. It supports voltages of up to 600 volts AC and 250 volts DC. The interrupt rating for this circuit breaker varies depending on the voltage, with a maximum of 65 kiloamps interrupting capacity (kAIC) at 240 volts AC and 35 kAIC at 480 volts AC.
Installation and connection are facilitated by its line and load terminals. The breaker is engineered to operate seamlessly within a frequency range of 50 to 60 Hertz (Hz), suitable for standard power systems. Its physical dimensions measure 3.38 inches in length, 6 inches in height, and 4.13 inches in width, with a weight of 4.5 pounds.
