FD3080 | Eaton Cutler-Hammer Series C F-Frame Molded Case Circuit Breaker 80A 3-Pole 600V
- Regular price
- $742.00
- Sale price
- $742.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FD3080
Description
The Eaton Cutler-Hammer FD3080 is a Series C molded case circuit breaker designed for dependable overload and short-circuit protection in industrial electrical systems. This three-pole breaker is rated at 80 A and operates at up to 600 VAC and 250 VDC using fixed thermal and fixed magnetic trip elements.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | FD3080 |
| Subcategory | Molded Case / 3-Pole |
| Series / Family | Series C |
| Frame Type | F-Frame |
| Breaker Type | FD |
| Number of Poles | 3 |
| Amperage Rating | 80 A |
| Voltage Rating | 600 VAC / 250 VDC |
| Phase | 3 |
| Trip Unit Type | Fixed Thermal / Fixed Magnetic |
| Protection Functions | LI – Long-Time and Instantaneous |
| Protection Technology | Thermal-Magnetic |
| Interrupt Rating | 35 kA at 480 V |
| Connection Type | Feed-Thru |
| Frequency Rating | 50/60 Hz |
Information About FD3080
The FD3080 is part of Eaton’s Cutler-Hammer Series C family and is built on an F-frame molded case platform for consistent industrial performance. It incorporates fixed thermal and magnetic trip elements that respond predictably to sustained overloads and instantaneous short-circuit conditions. The breaker is configured as a three-pole device to support three-phase electrical systems commonly found in industrial and commercial installations. Its design supports load-side applications where reliable interruption and long-term durability are required.
Key Features:
- Series C F-Frame Construction: Provides a robust molded case design suitable for demanding industrial power distribution environments.
- Fixed Thermal and Magnetic Trip Elements: Deliver stable and repeatable protection against overload and short-circuit conditions without adjustable settings.
- 80 Amp Current Rating: Supports medium-duty three-phase feeders and branch circuits.
- Three-Pole Configuration: Ensures coordinated protection and isolation of all phases in three-phase systems.
- High Interrupting Capacity: Rated at 35 kA at 480 V to safely interrupt high fault currents.
- Feed-Thru Connection Design: Facilitates clean conductor routing and straightforward integration into panels and switchgear.
- Dual Voltage Capability: Operates at up to 600 VAC and 250 VDC, supporting a wide range of electrical applications.
The FD3080 delivers the reliability and precision required for effective circuit protection in Eaton Cutler-Hammer Series C industrial electrical distribution systems.
