FD3150 | Eaton Series C F-Frame 150A 3-Pole Molded Case Circuit Breaker 600V
- Regular price
- $1,055.00
- Sale price
- $1,055.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FD3150
Description
The Eaton FD3150 is a Series C complete molded case circuit breaker designed for high-reliability overcurrent protection in industrial and commercial power systems. This three-pole breaker is rated at 150 A and operates at up to 600 VAC or 250 VDC using fixed thermal and fixed magnetic trip mechanisms.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | FD3150 |
| Subcategory | Molded Case Circuit Breaker |
| Series | Series C |
| Breaker Type | FD |
| Frame Type | F-Frame |
| Breaker Configuration | Complete breaker |
| Amperage Rating | 150 A |
| Voltage Rating | 600 VAC / 250 VDC |
| Number of Poles | 3 |
| Trip Type | Fixed thermal, fixed magnetic |
| Interrupt Rating | 65 kAIC at 240 VAC |
| Interrupt Rating (480 VAC) | 35 kAIC |
| Terminal Type | Line and load |
| Product Depth | 3.38 in |
| Product Height | 6 in |
| Product Width | 4.13 in |
| Weight | 4.5 lb |
Information About FD3150
The FD3150 is an Eaton Series C molded case circuit breaker built on the F-frame platform. It is manufactured as a complete breaker with non-adjustable thermal and magnetic trip elements to ensure consistent and predictable protection characteristics. The three-pole configuration supports use in three-phase AC systems as well as DC applications within rated limits. This breaker is commonly installed in commercial and industrial distribution equipment where high interrupting capacity and dependable Series C construction are required.
Key Features
- Series C F-Frame Design: Engineered for robust performance and compatibility within Eaton Series C power distribution systems.
- 150 Amp Continuous Rating: Suitable for feeder and branch circuit protection in industrial and commercial installations.
- Three-Pole Configuration: Provides balanced protection across three-phase electrical systems.
- Fixed Thermal and Magnetic Trip Units: Ensures stable overload and short-circuit protection without field adjustments.
- High Interrupting Capacity: Rated at 65 kAIC at 240 VAC and 35 kAIC at 480 VAC for systems with elevated fault current.
- Dual AC/DC Voltage Capability: Supports operation at up to 600 VAC and 250 VDC for flexible application use.
- Line and Load Terminals: Allows flexible installation orientation in panelboards and switchgear assemblies.
The FD3150 delivers the reliability and precision required for high-capacity circuit protection in Eaton Series C industrial and commercial electrical distribution systems.
