Festo JMFH-5-1/2 Bistable Pneumatic Solenoid Directional Control Valve
- Regular price
- $522.00
- Sale price
- $522.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: JMFH-5-1/2
Description
The Festo JMFH-5-1/2 is a bistable pneumatic solenoid valve for switching airflow to double-acting actuators. Its five-port, two-position configuration provides a standard nominal flow rate of 4,500 l/min at operating pressures of 2–8 bar. The valve uses G1/2 connections and a die-cast aluminum housing.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Festo |
| Category | Pneumatic Controls |
| Part Number | JMFH-5-1/2 |
| Subcategory | Directional Solenoid Valves |
| Series / Manufacturer Article Number | JMFH / 10166 |
| Valve Function | 5/2-way, double solenoid; bistable |
| Actuation / Piloting | Electrical / pilot operated |
| Design / Sealing Principle | Poppet seat / soft sealing |
| Standard Nominal Flow Rate | 4,500 l/min, standardized to DIN 1343 |
| Operating Pressure | 2–8 bar (0.2–0.8 MPa) |
| Main Pneumatic Connections | G1/2 at ports 1, 2, 3, 4, and 5 |
| Operating Voltage / Coil Connection | Determined by separately ordered F solenoid coils |
| Housing / Seal Materials | Die-cast aluminum / NBR and TPE-U (PU) |
| Construction Width / Grid Dimension | 52 mm / 69 mm |
| Nominal Size | 14 mm |
| Protection Class | IP65 with suitable electrical components installed |
| Manual Override / Exhaust Function | Detenting / throttleable exhaust |
| Ambient / Media Temperature | −5°C to +40°C / −10°C to +60°C |
| Mounting | Through-hole or manifold rail; any orientation |
| Weight | 1.21 kg (2.67 lb) |
Information About JMFH-5-1/2
The JMFH-5-1/2 is part of Festo’s JMFH series and carries manufacturer part number 10166. Its pilot-operated construction uses a soft-sealed poppet-seat mechanism. Electrical actuation requires compatible F solenoid coils, which are ordered separately and determine the operating voltage. Through-hole or manifold-rail mounting allows installation in any orientation.
Key Features:
- Bistable Operation: Provides two stable switching positions controlled by opposing electrical signals.
- Five-Port Configuration: Uses 5/2 directional control for compatible double-acting pneumatic actuators.
- High Flow Capacity: Provides a standard nominal airflow of 4,500 l/min.
- Poppet-Seat Design: Uses soft sealing surfaces within a pilot-operated valve mechanism.
- Pneumatic Connections: Incorporates G1/2 threads at all five main ports.
- Manual Override: Includes detenting overrides for manual switching.
- Throttleable Exhaust: Allows exhaust airflow restriction for circuit adjustment.
- Flexible Mounting: Supports through-hole or manifold-rail installation in any position.
The JMFH-5-1/2 delivers the reliability and precision required for high-flow pneumatic switching and actuator direction control in industrial machinery.
