FH26100AB | Square D FH Series 100A 2-Pole 600V I-Line Circuit Breaker
- Regular price
- $1,859.00
- Sale price
- $1,859.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FH26100AB
Description
The Square D FH26100AB is a two-pole molded case circuit breaker designed to deliver dependable overcurrent and short-circuit protection in high-voltage electrical distribution systems. Rated at 100 amps and 600 volts AC, this breaker uses thermal-magnetic trip technology to ensure stable protection under varying load conditions. It features I-Line style plug-in mounting for efficient installation in compatible panelboards.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Protection |
| Part Number | FH26100AB |
| Subcategory | Circuit Breakers |
| Series | FH |
| Product Type | Molded Case Circuit Breaker |
| Rated Current | 100 A |
| Number of Poles | 2 |
| Phase | Single Phase |
| Voltage Rating | 600 V AC |
| Protection Type | Thermal-Magnetic |
| Interrupting Rating | 25 kA @ 480 V AC |
| Connection Type | I-Line Style Plug-In |
| Functions | Long-Time and Instantaneous (LI) |
| Application | Power Distribution |
| Weight | 3.5 lb (approx.) |
Information About FH26100AB
The FH26100AB is part of Square D’s FH series within the I-Line family of molded case circuit breakers, engineered for compact design and reliable performance in commercial and industrial applications. This breaker incorporates a thermal-magnetic trip unit that provides long-time overload protection combined with instantaneous short-circuit response. Its I-Line style plug-in connection allows secure mechanical seating and consistent electrical contact within Square D distribution equipment. Designed for single-phase systems, the breaker meets industry requirements for safe and compliant circuit protection.
Key Features:
- 100 Amp Current Rating: Supports protection of higher-load branch and feeder circuits.
- Two-Pole Configuration: Designed for single-phase electrical system applications.
- 600V AC Voltage Rating: Suitable for high-voltage commercial and industrial environments.
- Thermal-Magnetic Protection: Combines long-time overload and instantaneous trip functions.
- I-Line Style Plug-In Mounting: Enables fast installation and secure electrical connection.
- High Interrupting Capacity: Rated up to 25 kA at 480 VAC for fault protection.
- FH Series Construction: Compact molded case design optimized for panelboard use.
The FH26100AB delivers the reliability and precision required for commercial and industrial power distribution protection.
