FieldServer FS-EZ3-MOD-BAC 500-Point Modbus to BACnet Protocol Gateway
- Regular price
- $1,089.00
- Sale price
- $1,089.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: FS-EZ3-MOD-BAC
Description
The FieldServer FS-EZ3-MOD-BAC is a 500-point protocol gateway designed to integrate Modbus devices with BACnet building and industrial automation networks. It supports Modbus RTU and Modbus TCP communication with BACnet Master-Slave/Token-Passing and BACnet Internet Protocol networks, providing serial and Ethernet connectivity for controllers, meters, sensors, and other field devices. Web-based configuration simplifies device mapping and commissioning without requiring separate configuration software.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | FieldServer |
| Category | Computer |
| Part Number | FS-EZ3-MOD-BAC |
| Subcategory | Computer Accessory |
| Product Family | EZ Gateway |
| Product Type | Modbus to BACnet Protocol Gateway |
| Point Capacity | 500 points |
| Supported Modbus Protocols | Modbus RTU, Modbus TCP |
| Supported BACnet Protocols | BACnet Master-Slave/Token-Passing, BACnet Internet Protocol |
| Ethernet Interface | 10/100 Base-T, automatic medium-dependent interface crossover |
| Serial Interfaces | One RS-485/RS-232 port and one RS-485 port |
| Power Input | 24 volts alternating current or 12 to 24 volts direct current |
| Typical Current Draw | 250 milliamperes at 12 volts direct current; 125 milliamperes at 24 volts direct current or alternating current |
| Maximum Power Consumption | 3 watts at 12 volts direct current |
| Configuration | Web-based configuration interface |
| Diagnostics | Onboard web diagnostics |
| Mounting | DIN rail mounting |
| Dimensions | 4 × 1.1 × 2.7 inches (10.2 × 2.8 × 6.8 centimeters) |
| Weight | 0.29 lbs |
Information About FS-EZ3-MOD-BAC
The FS-EZ3-MOD-BAC is part of the FieldServer EZ Gateway family developed for Modbus-to-BACnet protocol conversion in building management and industrial control systems. The unit combines serial communication interfaces with a 10/100 Base-T Ethernet interface and supports a maximum capacity of 500 registered data points. It is compatible with Modbus RTU, Modbus TCP, BACnet Master-Slave/Token-Passing, and BACnet Internet Protocol, allowing data from Modbus equipment to be exposed to BACnet supervisory systems. The gateway provides web-based configuration, onboard diagnostics, reusable device profiles, and DIN rail mounting for integration into automation control panels.
Key Features:
- 500-Point Gateway Capacity: Supports up to 500 registered data points for Modbus-to-BACnet integration.
- Multiple Protocol Support: Communicates using Modbus RTU, Modbus TCP, BACnet Master-Slave/Token-Passing, and BACnet Internet Protocol.
- Serial Communication: Provides serial connectivity for integration with Modbus and BACnet field networks.
- Ethernet Connectivity: Includes a 10/100 Base-T Ethernet interface for network communication and configuration.
- Web-Based Configuration: Internal web tools allow gateway configuration, device mapping, and diagnostics without separate configuration software.
- Flexible Power Input: Supports 24 volts alternating current or 12 to 24 volts direct current operation.
- Low Power Consumption: Maximum power requirement is approximately 3 watts at 12 volts direct current.
- Industrial Installation: Supports DIN rail mounting and is designed for installation in building and industrial automation systems.
The FS-EZ3-MOD-BAC delivers the reliability and precision required for Modbus-to-BACnet protocol conversion and field-device integration in building and industrial automation networks.
