Fire-Lite 411UD 4-Channel Dual-Line Slave Digital Alarm Communicator
- Regular price
- $289.00
- Sale price
- $289.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 411UD
Description
The Fire-Lite 411UD is a four-channel, dual-line Slave Digital Alarm Communicator Transmitter (DACT) designed to transmit fire alarm panel status information to a central or remote monitoring station. It monitors four programmable contact-closure inputs and provides remote upload/download capability, a programmable Form-C relay, and dual telephone-line communication.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Fire-Lite |
| Category | Fire Alarm Systems |
| Part Number | 411UD |
| Subcategory | Digital Alarm Communicators |
| Product Series | 411 Series |
| Product Type | Slave Digital Alarm Communicator Transmitter |
| Monitoring Channels | 4 |
| Telephone Lines | Dual Line |
| Input Activation | Contact Closure |
| Operating Power | 12 or 24 VDC, Jumper Selectable |
| Circuit Operating Voltage | 12 VDC |
| Alarm Current | 2.68 mA |
| End-of-Line Resistor | 2.2 kΩ, 1/2 W |
| Short-Circuit Current | 3.9 mA per Channel/Input |
| Relay Type | Programmable Form-C |
| Relay Contact Rating | 2.0 A at 30 VDC, Resistive |
| Programming Device | PRO-411 Hand-Held Programmer |
| Remote Programming | Upload/Download Capability |
| Approvals | UL, MEA, CSFM |
| Weight | 5 lb |
Information About 411UD
The 411UD is a Fire-Lite 411 Series slave digital alarm communicator designed to interface with compatible host fire alarm control panels through monitored contact inputs. Its four channels can be individually programmed for conditions including fire alarm, system trouble, supervisory, AC power loss, security alarm, process monitoring, and other fire or non-fire events. The communicator uses two telephone lines for reporting and includes a programmable Form-C relay, diagnostic LEDs, an integral piezo sounder, and selectable 12 or 24 VDC input operation. Local configuration is performed with the PRO-411 hand-held programmer, while the 411UD also supports remote programming, upload/download, and real-time status functions through compatible software.
Key Features:
- Four Monitoring Channels: Provides four programmable contact-closure inputs for monitoring host fire alarm panel conditions.
- Dual-Line DACT: Uses two telephone lines for digital alarm communication with compatible monitoring stations.
- Programmable Inputs: Channels can monitor alarm, trouble, supervisory, AC loss, security, process, and other assigned conditions.
- Form-C Relay: Includes a programmable Form-C relay rated at 2.0 A at 30 VDC resistive.
- 12/24 VDC Operation: Jumper-selectable configuration permits operation from compatible 12 or 24 VDC power sources.
- Upload/Download Capability: Supports remote programming and real-time status access with compatible 411UD software.
- Local Programming: Compatible with the Fire-Lite PRO-411 hand-held DACT programmer for configuration and troubleshooting.
- Diagnostic Indication: Provides LEDs for communication failure, DACT trouble, channel activity, telephone-line activity, and modem operation.
The 411UD delivers the reliability and precision required for transmitting fire alarm, supervisory, trouble, and auxiliary status information to remote monitoring stations.
