Fireye AC6A3BD 120V Rotary Actuator 0–75° Rotation 20 lb-in Torque
- Regular price
- $3,099.00
- Sale price
- $3,099.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: AC6A3BD
Description
The Fireye AC6A3BD is a 120 VAC rotary actuator designed for precise mechanical positioning in combustion and burner control systems. It provides 0–75° shaft rotation with 20 lb-in of torque and a 75° travel time of 18 seconds at 60 Hz.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Fireye |
| Category | Burner Controls |
| Part Number | AC6A3BD |
| Subcategory | Rotary Actuators |
| Operating Voltage | 120 VAC |
| Frequency | 50/60 Hz |
| Carburetor Model | HDA-252 |
| Shaft Rotation | 0–75° |
| Torque | 20 lb-in (2.3 N-m) |
| Speed | 18 seconds for 75° at 60 Hz |
| Operating Temperature | 0 to 140°F (-20 to +60°C) |
| Weight | 1.36 kg |
Information About AC6A3BD
The AC6A3BD is a Fireye rotary actuator intended for applications requiring controlled angular shaft positioning. It operates from a 120 VAC supply at either 50 or 60 Hz and is designed for an operating temperature range of 0 to 140°F (-20 to +60°C). The actuator provides 2.3 N-m of torque with a maximum shaft rotation of 75 degrees. The AC6A3BD is also specified as a replacement for Eclipse part number PRA6A3BD.
Key Features:
- Rotary Actuator: Provides controlled shaft positioning for burner and combustion control applications.
- 120 VAC Operation: Designed for connection to a 120 VAC power supply.
- Frequency Compatibility: Supports both 50 Hz and 60 Hz operating frequencies.
- Shaft Rotation: Provides adjustable mechanical rotation through a 0–75° range.
- Torque Output: Delivers 20 lb-in (2.3 N-m) of rotational torque.
- Operating Speed: Completes 75° of shaft rotation in 18 seconds at 60 Hz.
- Temperature Range: Rated for operation from 0 to 140°F (-20 to +60°C).
- Replacement Compatibility: Replaces Eclipse part number PRA6A3BD.
The AC6A3BD delivers the reliability and precision required for burner actuator and combustion control applications.
