Fireye NXC12 12 Nm 4-Wire CANbus Servo Motor 24-30 VAC for NX Combustion Control
- Regular price
- $1,289.00
- Sale price
- $1,289.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NXC12
Description
The Fireye NXC12 is a 12 Nm CANbus servo motor designed for precise positioning of fuel valves, air dampers, and other rotary devices in Fireye NX-series combustion control systems. Fireye part number NXC12 operates from a 24–30 VAC supply provided by the associated control unit and combines digital actuator communication with controlled 90-degree rotation for coordinated burner air-to-fuel control.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Fireye |
| Category | Combustion Controls |
| Part Number | NXC12 |
| Subcategory | Servo Motors |
| Series | Fireye NXC Series |
| Product Type | CANbus Servo Motor / Rotary Actuator |
| Compatible System | Fireye NX-Series Combustion Controls |
| Compatible Control Platform | Fireye NX6100 |
| Communication Protocol | CANbus |
| Wiring Configuration | 4-Wire |
| Supply Voltage | 24–30 VAC, Supplied from Control Unit |
| Supply Frequency | 50/60 Hz |
| Driving Torque | 12 Nm (Approx. 8.9 ft-lb) |
| Rotation Range | 90° |
| Enclosure Rating | IP54 / NEMA 3S |
| Operating Temperature Range | 32°F to 140°F (0°C to 60°C) |
| Primary Application | Fuel Valve and Combustion-Air Damper Positioning |
| Equipment Applications | Boilers, Furnaces, Industrial Burners, Process Heating Systems |
| Weight | Approx. 5 lb |
Information About NXC12
The NXC12 is part of the Fireye NXC Series of digital servo motors developed for integration with NX-series burner management and parallel-positioning systems, including the NX6100 platform. Its industrial actuator construction delivers 12 Nm of driving torque while a 4-wire CANbus interface carries power and digital communication between the servo and compatible Fireye controller. The actuator provides controlled 90-degree rotary travel and allows the combustion control system to command and supervise the position of connected fuel valves, air dampers, and similar burner components. Designed for boiler, furnace, process-heating, and industrial burner applications, the NXC12 provides an intermediate torque option where precise positioning is required without the higher output of larger NXC-series actuators.
Key Features:
- 12 Nm Driving Torque: Provides approximately 12 Nm (8.9 ft-lb) of torque for positioning compatible combustion-control devices.
- CANbus Communication: Digital communication enables integration with compatible Fireye NX burner control platforms.
- 4-Wire Connection: Uses a simplified four-wire arrangement for actuator power and CANbus communications.
- NX System Compatibility: Designed for use with Fireye NX-series combustion management and parallel-positioning controls.
- 24–30 VAC Operation: Receives low-voltage operating power from the associated Fireye control unit.
- 90-Degree Rotary Travel: Provides quarter-turn movement suitable for common fuel-valve and air-damper applications.
- Controlled Positioning: Enables accurate positioning of connected combustion equipment throughout the burner firing range.
- Position Supervision: CANbus architecture allows the compatible controller to supervise servo position during burner operation.
- Protected Enclosure: IP54 / NEMA 3S construction provides protection for industrial combustion-control installations.
- Fuel and Air Control: Suitable for controlling gas valves, oil valves, combustion-air dampers, and related rotary mechanisms.
- Industrial Temperature Capability: Designed for operation from 32°F to 140°F (0°C to 60°C).
- Burner Management Application: Supports coordinated fuel-to-air positioning in boilers, furnaces, ovens, and process combustion equipment.
The NXC12 delivers the reliability and precision required for coordinated fuel and combustion-air positioning in industrial burner management systems.
