FX-5R | Edwards Signaling 5-Zone Conventional Fire Alarm Control Panel, 120 VAC, 24 VDC
- Regular price
- $679.00
- Sale price
- $679.00
- Regular price
-
$0.00
Couldn't load pickup availability
Do you need help?
Product Description P/N: FX-5R
Description
The Edwards Signaling FX-5R is a 5-zone conventional fire alarm control panel designed for reliable fire detection and notification in commercial and institutional applications. This steel-constructed unit supports Class B IDCs and NACs, with the option to convert to Class A circuits, ensuring flexible installation and dependable operation. With integrated features such as CleanMe and drift compensation, the FX-5R reduces false alarms and extends detector life.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Edwards Signaling |
| Category | Fire Safety |
| Part Number | FX-5R |
| Subcategory | Fire Alarm Control |
| Type | 5-Zone Conventional Fire Alarm Control Panel |
| Series | FX Series |
| Circuit Inputs | 5 IDCs (Class B, convertible to Class A) |
| Circuit Outputs | 2 NACs (Class B, convertible to Class A) |
| NAC Power Capacity | 3.5 A per panel, 2 A per circuit |
| Input Power | 120 VAC |
| Output Power | 24 VDC |
| Display Type | LCD |
| Temperature Rating | 32°F to 120°F (0°C to 49°C) |
| Cabinet Material | Steel |
| Color | Red |
| Dimensions | 19.5 in H × 14.25 in W × 3.75 in D |
| Certifications | ANSI/UL 864 9th Edition, CSFM Approved, FDNY Approved |
| Mounting | Wall mount |
| Weight | 24.00 lbs |
Information About FX-5R
The FX-5R is part of the Edwards FX Series, which includes conventional fire alarm panels built to meet ANSI/UL 864 9th Edition standards. It is equipped with five initiating device circuits and two notification appliance circuits, both convertible to Class A configurations for added system resilience. The panel provides 3.5A of NAC power and includes features such as zone-level programmability, annunciation, and synchronization with compatible notification appliances. Its rugged steel housing, LCD display, and compatibility with serial annunciator and relay modules make it suitable for a wide range of fire protection systems in mid-sized facilities.
Key Features:
- Five Initiating Device Circuits: Supports up to five Class B IDCs, convertible to Class A.
- Two Notification Appliance Circuits: Each Class B, with option to convert to Class A for enhanced reliability.
- 3.5A NAC Power Supply: Provides sufficient capacity for multiple notification appliances.
- CleanMe and Drift Compensation: Maintains detector sensitivity and reduces nuisance alarms.
- Programmable Operation: Allows zone and NAC customization directly from the front panel.
- Integrated DACT Option: Enables upload/download capability and PC programming.
- Steel Cabinet Construction: Ensures durability and long service life in demanding environments.
- UL and CSFM Approved: Meets industry safety standards for fire alarm systems.
The FX-5R delivers the reliability and flexibility required for professional fire detection and alarm installations.
