Product Description P/N: G3PB-545B-3N-VD
Description
The Omron G3PB-545B-3N-VD Solid State Contactor is a three-phase, zero-cross switching relay designed for high-capacity AC load control up to 45 A at 180–528 VAC. Operated via a 9.6–30 VDC control voltage, it provides silent, fast, and reliable switching for heaters, motors, and resistive loads. Featuring an integrated heat sink and chassis or DIN rail mounting, the G3PB-545B-3N-VD ensures efficient thermal management and long operational life in industrial environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron Automation and Safety |
| Category | Industrial Relays |
| Part Number | G3PB-545B-3N-VD |
| Subcategory | Solid State Contactors |
| Series | G3PB Series |
| Type | Three-Phase Solid State Relay (Zero Cross) |
| Circuit Type | 3PST-NO (3 Form A) |
| Output Type | AC, Zero Cross Switching |
| Load Current | 45 A |
| Load Voltage Range | 180–528 VAC |
| Control Voltage Range | 9.6–30 VDC |
| Input Current | 10 mA typical |
| Operating Frequency | 50/60 Hz |
| Mounting Type | Chassis Mount / DIN Rail Mount |
| Termination Style | Screw Terminals |
| Cooling | Integrated Heat Sink |
| Package / Case | SSR with Integrated Heat Sink |
| Isolation Resistance | 1000 MΩ min. (at 500 VDC) |
| Dielectric Strength | 4000 VAC between input and output |
| Operating Temperature | -30°C to +80°C |
| Enclosure Material | Aluminum Heat Sink with Plastic Housing |
| LED Indicator | Input Status Indication |
| Product Status | Obsolete |
| Application | Heater Control, Motor Control, Industrial Power Switching |
| Unit Weight | 14.1 oz (approx. 400 g) |
| Country of Origin | Japan |
Information About G3PB-545B-3N-VD
The G3PB-545B-3N-VD is part of the Omron G3PB Series, a line of compact three-phase solid state contactors engineered for precision AC load switching. Utilizing zero-cross technology, it minimizes electrical noise and surge currents during operation, enhancing load and contactor longevity. This model supports control voltages from 9.6–30 VDC and operates over a wide load voltage range from 180–528 VAC, making it suitable for both resistive and some inductive loads. Designed with screw terminals and an integrated heat sink, the G3PB-545B-3N-VD simplifies installation and ensures optimal performance under continuous-duty conditions.
Key Features:
- Three-Phase Switching: Controls all three phases simultaneously for balanced load operation.
- High Load Capacity: Rated at 45 A with load voltages up to 528 VAC for industrial applications.
- Zero-Cross Triggering: Reduces electrical noise and inrush current during load activation.
- Wide Control Voltage Range: Accepts 9.6–30 VDC for flexible system integration.
- Integrated Heat Sink: Ensures efficient heat dissipation under continuous operation.
- Dual Mounting Options: Supports both chassis and DIN rail installation for convenience.
- Fast, Silent Operation: No mechanical contacts, eliminating arcing and contact wear.
- Industrial Durability: Built for long-term use in heating, motor, and process control applications.
The G3PB-545B-3N-VD delivers the reliability and precision required for high-performance AC load switching in industrial automation and temperature control systems.
