Gamewell-FCI ACM-30 Remote Fire Alarm Annunciator for Elevate Platform FACP with Programmable Touch Controls
- Regular price
- $599.00
- Sale price
- $599.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: ACM-30
Description
The Gamewell-FCI ACM-30 is a remote serial annunciator designed to extend monitoring and control capabilities for Gamewell-FCI Elevate Platform Fire Alarm Control Panels (FACPs). Featuring 30 programmable capacitive touch buttons with dual-color LED indicators, the Gamewell-FCI ACM-30 provides flexible remote system control, status indication, and alarm management for commercial fire alarm installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Gamewell-FCI |
| Category | Fire Alarm Systems |
| Part Number | ACM-30 |
| Subcategory | Remote Fire Alarm Annunciator |
| Compatible Series | Gamewell-FCI Elevate Platform |
| Product Type | Remote Serial Annunciator |
| Communication Interface | AIO Bus (2-wire supervised serial communication) |
| Maximum Annunciators per Panel | Up to 10 |
| Control Buttons | 30 programmable capacitive touch buttons |
| LED Indicators | 62 total LEDs (60 programmable + 2 system LEDs) |
| LED Colors | Red, Green, Yellow, White, Amber, Blue, Cyan, Purple |
| Programming Modes | Independent Mode or Cooperative Mode |
| System Functions | Signal Silence, System Reset, Local Acknowledge, Lamp Test |
| Audible Notification | Integrated programmable piezo sounder |
| Operating Voltage | 24 VDC |
| Power Requirement | 18–30 VDC, 83 mA standby at 24 VDC, 93 mA alarm at 24 VDC |
| Communication Wiring | Four-wire connection to EIA-485 (two communication + two 24 VDC power) |
| Operating Temperature | 0°C to 49°C (32°F to 120°F) |
| Relative Humidity | Up to 93% non-condensing at 32°C (90°F) |
| Mounting | GFP-BB-RA surface-mount enclosure |
| Terminal Type | Removable compression-type plug-in terminal blocks |
| Application | Remote fire alarm monitoring and system control |
| Weight | Approximately 1.8 lb (0.82 kg) |
Information About ACM-30
The ACM-30 is a programmable remote annunciator developed for the Gamewell-FCI Elevate Platform fire alarm system family. It communicates with compatible FACPs over the supervised two-wire AIO Bus, allowing operators to monitor system conditions and execute control functions from remote locations. The annunciator features a capacitive touch keypad with fully programmable buttons and multi-color LED indicators that can operate in cooperative or independent modes depending on system programming requirements. Designed for commercial life safety applications, it supports remote acknowledge, signal silence, system reset, lamp test, and other custom control functions while maintaining continuous supervision of communications and power.
Key Features:
- 30 Capacitive Touch Buttons: Provides responsive programmable touch controls for remote fire alarm system operation.
- 60 Programmable LED Indicators: Two LEDs per button support customized point status indication.
- Eight LED Color Options: Supports red, green, yellow, white, amber, blue, cyan, and purple LED programming.
- Independent or Cooperative Programming: Buttons and LEDs may function together or operate independently for maximum flexibility.
- Remote System Control: Supports Signal Silence, System Reset, Local Acknowledge, and Lamp Test functions.
- AIO Bus Communication: Uses a supervised two-wire serial communication interface with the Elevate Platform FACP.
- On-Line/Power and Trouble Indicators: Dedicated LEDs continuously display communication and system status.
- Integrated Piezo Sounder: Provides local audible notification for alarm and trouble conditions.
- Configurable Audible Indication: Local buzzer can be enabled or disabled through programming or hardware settings.
- Supports Multiple Annunciators: One compatible control panel supports up to ten ACM-30 annunciators.
- 24 VDC Operation: Powered through a supervised 24 VDC power-limited circuit from the fire alarm control panel or approved remote supply.
- Removable Terminal Blocks: Compression-type plug-in terminals simplify installation, maintenance, and field wiring.
The ACM-30 delivers the reliability and precision required for remote fire alarm monitoring, system annunciation, and operator control in commercial life safety systems.
