General Electric TED136YT150 150A 3-Pole 600V Molded Case Switch
- Regular price
- $2,899.00
- Sale price
- $2,899.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TED136YT150
Description
The General Electric TED136YT150 is a 150 Amp, 3-pole molded case switch designed for three-phase electrical systems. It provides non-automatic protection for circuits operating up to 600 VAC or 500 VDC. This switch is compatible with GE A-Series and Spectra Series panelboards, ensuring secure and reliable installation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | General Electric |
| Category | Molded Case Circuit Breakers / 3-Pole |
| Part Number | TED136YT150 |
| Subcategory | Molded Case Switch |
| Series | TED |
| Poles | 3 |
| Current Rating | 150 Amp |
| Voltage Rating | 240VAC, 480VAC, 600VAC, 250VDC, 500VDC |
| Phase | Three-Phase |
| Trip Type | Magnetic Only |
| Trip Adjustability | Fixed |
| Mounting Type | Bolt-On |
| Terminal Type | Lugs |
| Wire Range | 3 AWG – 3/0 AWG (Cu), 1 AWG – 3/0 AWG (Al) |
| Interrupting Capacity | 18kA @ 480V, 18kA @ 240/480VAC, 14kA @ 600VAC, 10kA @ 250/500VDC |
| Optional Features | Shunt Trip, Auxiliary Switch, Undervoltage Release, Bell Alarm, Motor Operator, Padlock Attachment |
| Standards | UL 489, NEMA AB 1, CSA C22.2 No. 5 |
| Approvals | UL, CSA |
| Operating Temperature | 40°C |
| Construction Features | Non-Automatic, Molded Case Switch, Feed-Thru |
| Dimensions (HxWxD) | 6.75 x 4.25 x 4.75 in |
| Weight | 5 lbs |
Information About TED136YT150
The TED136YT150 is part of GE’s TED series of molded case switches, built for industrial and commercial applications. It features a bolt-on mounting style with lug terminals for feed-thru connections. The switch uses a magnetic-only trip mechanism with fixed settings and accommodates wire sizes from 3 AWG to 3/0 AWG for copper and 1 AWG to 3/0 AWG for aluminum. Optional features include shunt trip, auxiliary switch, undervoltage release, bell alarm, motor operator, and padlock attachment for flexible installation.
Key Features:
- Series: TED Series molded case switch for industrial use.
- Poles: 3-pole configuration for three-phase systems.
- Current Rating: 150 Amp continuous load capacity.
- Voltage Rating: 240VAC, 480VAC, 600VAC, 250VDC, 500VDC compatible.
- Mounting Style: Bolt-on for secure panel installation.
- Trip Mechanism: Magnetic-only with fixed trip setting.
- Wire Range: 3 AWG – 3/0 AWG (Cu), 1 AWG – 3/0 AWG (Al).
- Compatibility: Fits GE A-Series and Spectra Series panelboards.
- Optional Features: Shunt trip, auxiliary switch, undervoltage release, bell alarm, motor operator, padlock attachment.
The TED136YT150 delivers the reliability and precision required for industrial and commercial circuit control.
