General Electric TR16B800 Rating Plug 800A for Spectra RMS Power Break II with 1600A Sensor
- Regular price
- $545.00
- Sale price
- $545.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: TR16B800
Description
The General Electric TR16B800 rating plug is a precision component designed to set the current rating of compatible circuit breakers within Spectra RMS and Power Break systems. Rated at 800 A, it enables accurate adjustment of protection parameters for reliable system performance. This plug ensures consistent calibration of trip units in electrical distribution and control applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | General Electric |
| Category | Circuit Breaker Accessories |
| Part Number | TR16B800 |
| Subcategory | Rating Plugs |
| Series | Spectra RMS / Power Break II |
| Rated Current | 800 A |
| Sensor Rating | 1600 A |
| Trip Unit Compatibility | MicroVersaTrip Plus / PM |
| Function | Current rating configuration |
| Installation Type | Plug-in |
| Application | Electrical distribution and control |
| Certification | UL Listed |
| Weight | 1 lb (approx. 0.45 kg) |
Information About TR16B800
The TR16B800 is part of General Electric’s rating plug lineup used with Spectra RMS and Power Break II circuit breakers. It is engineered to define the continuous current rating of breakers equipped with MicroVersaTrip Plus or PM electronic trip units. Designed to work with a 1600 A current sensor, it allows a higher-capacity breaker frame to operate at a reduced 800 A rating for precise system coordination. This component is widely used in industrial and commercial power distribution systems where flexible configuration and accurate protection are required.
Key Features:
- Current Rating Configuration: Sets breaker trip unit rating to 800 A for precise protection control
- Sensor Compatibility: Designed for use with 1600 A current sensors
- Spectra RMS Integration: Compatible with GE Spectra RMS and Power Break II systems
- Electronic Trip Unit Support: Works with MicroVersaTrip Plus and PM trip units
- Plug-In Design: Enables quick installation and replacement without modifying the breaker
- Precision Calibration: Ensures accurate and stable current measurement
- UL Listed: Meets recognized safety and compliance standards
- Flexible Application: Suitable for electrical distribution and control systems
The TR16B800 delivers the reliability and precision required for accurate current setting and protection configuration in circuit breaker systems.
