GFPS-6 | Gamewell-FCI NAC Expander / Power Supply, 6A Output, Red
- Regular price
- $1,399.00
- Sale price
- $1,399.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: GFPS-6
Description
The Gamewell-FCI GFPS-6 is a NAC expander and power supply that provides up to 6 amps of regulated 24VDC power for notification appliances. It supports multiple Class A and Class B circuits, synchronization for leading strobe manufacturers, and includes supervision and trouble monitoring features.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Gamewell-FCI |
| Category | Fire Alarm Systems |
| Part Number | GFPS-6 |
| Subcategory | NAC Panels |
| Type | NAC Expander / Power Supply |
| Output Voltage | 24 VDC regulated |
| Alarm Output | 6.0 A max. @ 24 VDC (nominal) |
| Output Circuits | 2 Class A (Style Z), 4 Class B (Style Y), or 1 Class A + 2 Class B |
| Current per Circuit | Up to 3 A per output |
| Auxiliary Output | Continuous 24VDC output |
| Inputs | 2 inputs, configurable as 2 Class A or 2 Class B |
| Synchronization | Built-in sync for System Sensor, Gentex, Wheelock, AMSECO, Faraday |
| Temporal Pattern | Programmable ANSI S3.41 Class B output |
| Supervision | Integral ground fault detection |
| Trouble Reporting | Form “C” trouble contacts with delayed AC failure indication |
| Supervisory Current | 0.075 A |
| Alarm Current | 0.175 A (excluding notification appliances) |
| Operating Power | 120 VAC, 2.7 A, 60 Hz |
| Standby Battery | 24 VDC, up to 33 Ah |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Humidity Range | Up to 85% non-condensing |
| Enclosure Color | Red |
| Compliance | UL Listed as a fire alarm accessory |
| Dimensions | 16 × 12.25 × 3 in |
| Weight | 8 lbs |
Information About GFPS-6
The GFPS-6 is part of Gamewell-FCI’s NAC expander and auxiliary power supply lineup, designed to increase notification appliance capacity in fire alarm systems. It provides up to 6 amps of regulated 24VDC output and supports multiple Class A and Class B wiring configurations for greater installation flexibility. With built-in synchronization for strobes and horns from leading manufacturers, it ensures code-compliant visual and audible signaling. The panel also includes ANSI S3.41 temporal pattern outputs, ground fault detection, and trouble monitoring via Form “C” contacts, making it a robust and reliable accessory for expanding fire alarm capabilities.
Key Features:
- High-capacity output: Provides 6 amps of regulated 24VDC power to support multiple NAC devices.
- Flexible wiring options: Configurable as 2 Class A, 4 Class B, or a mixed 1 Class A and 2 Class B circuit arrangement.
- Auxiliary 24VDC output: Supplies continuous power for compatible system components or accessories.
- Synchronization support: Built-in sync for notification appliances from System Sensor, Gentex, Wheelock, AMSECO, and Faraday.
- Temporal pattern capability: Offers ANSI S3.41-compliant temporal outputs for standardized fire alarm signaling.
- Supervised operation: Integral ground fault detection ensures reliability and system integrity.
- Trouble monitoring: Equipped with Form “C” trouble contacts and delayed AC failure indication for detailed reporting.
- Wide device compatibility: UL Listed for use with Gamewell-FCI and other UL Listed fire alarm control panels.
- Durable red enclosure: Compact design built for professional installation and long-term reliability.
- Environmental tolerance: Operates across broad temperature and humidity ranges for diverse site conditions.
The GFPS-6 delivers the reliability and precision required for expanding NAC capacity and providing dependable power in commercial and institutional fire alarm systems.
Description
The Gamewell-FCI GFPS-6 is a NAC expander and power supply that provides up to 6 amps of regulated 24VDC power for notification appliances. It supports multiple Class A and Class B circuits, synchronization for leading strobe manufacturers, and includes supervision and trouble monitoring features.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Gamewell-FCI |
| Category | Fire Alarm Systems |
| Part Number | GFPS-6 |
| Subcategory | NAC Panels |
| Type | NAC Expander / Power Supply |
| Output Voltage | 24 VDC regulated |
| Alarm Output | 6.0 A max. @ 24 VDC (nominal) |
| Output Circuits | 2 Class A (Style Z), 4 Class B (Style Y), or 1 Class A + 2 Class B |
| Current per Circuit | Up to 3 A per output |
| Auxiliary Output | Continuous 24VDC output |
| Inputs | 2 inputs, configurable as 2 Class A or 2 Class B |
| Synchronization | Built-in sync for System Sensor, Gentex, Wheelock, AMSECO, Faraday |
| Temporal Pattern | Programmable ANSI S3.41 Class B output |
| Supervision | Integral ground fault detection |
| Trouble Reporting | Form “C” trouble contacts with delayed AC failure indication |
| Supervisory Current | 0.075 A |
| Alarm Current | 0.175 A (excluding notification appliances) |
| Operating Power | 120 VAC, 2.7 A, 60 Hz |
| Standby Battery | 24 VDC, up to 33 Ah |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Humidity Range | Up to 85% non-condensing |
| Enclosure Color | Red |
| Compliance | UL Listed as a fire alarm accessory |
| Dimensions | 16 × 12.25 × 3 in |
| Weight | 8 lbs |
Information About GFPS-6
The GFPS-6 is part of Gamewell-FCI’s NAC expander and auxiliary power supply lineup, designed to increase notification appliance capacity in fire alarm systems. It provides up to 6 amps of regulated 24VDC output and supports multiple Class A and Class B wiring configurations for greater installation flexibility. With built-in synchronization for strobes and horns from leading manufacturers, it ensures code-compliant visual and audible signaling. The panel also includes ANSI S3.41 temporal pattern outputs, ground fault detection, and trouble monitoring via Form “C” contacts, making it a robust and reliable accessory for expanding fire alarm capabilities.
Key Features:
- High-capacity output: Provides 6 amps of regulated 24VDC power to support multiple NAC devices.
- Flexible wiring options: Configurable as 2 Class A, 4 Class B, or a mixed 1 Class A and 2 Class B circuit arrangement.
- Auxiliary 24VDC output: Supplies continuous power for compatible system components or accessories.
- Synchronization support: Built-in sync for notification appliances from System Sensor, Gentex, Wheelock, AMSECO, and Faraday.
- Temporal pattern capability: Offers ANSI S3.41-compliant temporal outputs for standardized fire alarm signaling.
- Supervised operation: Integral ground fault detection ensures reliability and system integrity.
- Trouble monitoring: Equipped with Form “C” trouble contacts and delayed AC failure indication for detailed reporting.
- Wide device compatibility: UL Listed for use with Gamewell-FCI and other UL Listed fire alarm control panels.
- Durable red enclosure: Compact design built for professional installation and long-term reliability.
- Environmental tolerance: Operates across broad temperature and humidity ranges for diverse site conditions.
The GFPS-6 delivers the reliability and precision required for expanding NAC capacity and providing dependable power in commercial and institutional fire alarm systems.
