GHB1015 | Eaton 15A Single-Pole 277/480V Thermal Magnetic Bolt-On Circuit Breaker
- Regular price
- $184.00
- Sale price
- $184.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: GHB1015
Description
The Eaton GHB1015 is a single-pole molded case circuit breaker designed for 15A protection in 277/480V single-phase systems and 125VDC circuits. Its bolt-on mounting, thermal magnetic LI trip unit, and compatibility with reverse-feed applications ensure reliable performance in commercial and industrial installations.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | GHB1015 |
| Subcategory | Molded Case Circuit Breaker |
| Family | Series C |
| Type | GHB |
| Voltage | 277/480 V AC, 125 V DC |
| Amperage | 15 A |
| Connection | Bolt-On |
| Functions | LI – Long-Time and Instantaneous |
| Phase | 1 |
| Frame Type | G Frame |
| AIC Rating | 14 kA @ 277 V |
| Poles | 1 |
| Protection | Thermal Magnetic |
| Interrupting Capacity | Standard |
| Trip Unit | Non-Interchangeable Trip |
| Reverse Feed Capability | Suitable for Reverse Feed Use |
| Temperature Rating | 40 °C |
| Application | Commercial and Industrial Branch Circuit Protection |
Information About GHB1015
The GHB1015 is part of Eaton’s Series C molded case circuit breaker line, built on the durable G Frame platform for long-term reliability. It supports 15A branch circuit protection in 277/480V AC systems as well as low-voltage DC installations, making it versatile for lighting, control circuits, and auxiliary loads. The breaker incorporates a thermal magnetic LI trip mechanism that provides both overload response and rapid short-circuit interruption, ensuring dependable system safety. Its bolt-on construction and reverse-feed capability make it suitable for diverse panel configurations in commercial and industrial facilities.
Key Features
- 15A single-pole breaker: Suitable for 277/480V AC circuits and 125VDC applications.
- Thermal magnetic LI protection: Combines overload and instantaneous short-circuit trip functions.
- 14 kA interrupt rating: Ensures dependable fault-clearing capability at 277V.
- Bolt-on connection: Provides secure mechanical and electrical contact in Series C panelboards.
- Reverse-feed capable: Supports flexible installation in specialized electrical configurations.
- G Frame durability: Offers long-term mechanical and thermal performance.
- UL-listed reliability: Suitable for commercial and industrial distribution systems.
- Compact molded case design: Fits standard panel layouts with minimal space requirements.
The GHB1015 delivers the reliability and precision required for safe electrical protection across commercial and industrial AC and DC systems.
