GHB3040 | Eaton Series C Complete Molded Case Circuit Breaker
- Regular price
- $409.00
- Sale price
- $409.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: GHB3040
Description
The GHB3040 is a molded case circuit breaker manufactured by Eaton, belonging to the Series C lineup. It features a G-frame design and is categorized under the GHB circuit breaker type. Operating as a complete breaker, it incorporates fixed thermal and fixed magnetic trip mechanisms. This three-pole circuit breaker has a current rating of 40 A and operates at voltages of 480Y/277 Vac and 125/250 Vdc. It supports frequencies of 50/60 Hz, making it suitable for a variety of electrical systems.
Technical Specifications
|
PRODUCT NAME |
Eaton Series C complete molded case circuit breaker |
|
CATALOG NUMBER |
GHB3040 |
|
UPC |
786679911280 |
|
PRODUCT LENGTH/DEPTH |
2.63 in |
|
PRODUCT HEIGHT |
4 in |
|
PRODUCT WIDTH |
3 in |
|
PRODUCT WEIGHT |
1.75 lb |
|
TYPE |
Molded case circuit breaker |
|
AMPERAGE RATING |
40 A |
|
VOLTAGE RATING |
480Y/277 Vac, 125/250 Vdc |
|
TRIP TYPE |
Fixed thermal, fixed magnetic |
|
CIRCUIT BREAKER TYPE |
GHB |
|
CIRCUIT BREAKER FRAME TYPE |
Complete breaker |
|
SERIES |
Series C |
|
FRAME |
G |
|
FREQUENCY RATING |
50/60 Hz |
|
INTERRUPT RATING |
14 kAIC at 480Y/277 Vac |
|
|
65 kAIC at 240 Vac |
|
NUMBER OF POLES |
Three-pole |
Information About GHB3040
The GHB3040 is a molded case circuit breaker manufactured by Eaton, falling under the Series C lineup. It features a G-frame design and corresponds to the GHB circuit breaker type. Functioning as a complete breaker, it incorporates fixed thermal and fixed magnetic trip mechanisms. This circuit breaker is configured as a three-pole unit with a current rating of 40 A.
In terms of voltage compatibility, the GHB3040 operates at 480Y/277 Vac and 125/250 Vdc. It supports frequencies of 50/60 Hz, making it suitable for various electrical systems.
With dimensions measuring 2.63 inches in length, 4 inches in height, and 3 inches in width, the GHB3040 is compact and suitable for installation in confined spaces. It weighs 1.75 pounds, facilitating ease of handling during installation and maintenance procedures.
The interrupting rating of the GHB3040 varies depending on the voltage level. At 480Y/277 Vac, it offers an interrupting capacity of 14 kAIC, while at 240 Vac, it provides a higher rating of 65 kAIC. This ensures reliable protection against short circuits and overloads in electrical systems.
Manufacturer information
Eaton Corporation is a multinational power management company offering a diverse range of electrical, hydraulic, and aerospace solutions. Known for innovation, Eaton serves customers in various industries worldwide.
