GHB3070 | Eaton Series C Complete Molded Case Circuit Breaker
- Regular price
- $499.00
- Sale price
- $499.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: GHB3070
Description
The GHB3070 is a three-pole Eaton Series C complete molded case circuit breaker featuring a G-frame design. It is equipped with fixed thermal and fixed magnetic trip types for reliable operation. With a current rating of 70 A, this circuit breaker is suitable for applications requiring 480Y/277 Vac and 125/250 Vdc voltage ratings, operating at frequencies of 50/60 Hz.
Technical Specifications
|
Product Name |
Eaton Series C complete molded case circuit breaker |
|
Catalog Number |
GHB3070 |
|
UPC |
786679911310 |
|
Product Length/Depth |
2.63 in |
|
Product Height |
4 in |
|
Product Width |
3 in |
|
Product Weight |
1.75 lb |
|
Type |
Molded case circuit breaker |
|
Amperage Rating |
70A |
|
Voltage Rating |
480Y/277 Vac, 125/250 Vdc |
|
Trip Type |
Fixed thermal, fixed magnetic |
|
Circuit Breaker Type |
GHB |
|
Circuit Breaker Frame Type |
Complete breaker |
|
Series |
Series C |
|
Frame |
G |
|
Frequency Rating |
50/60 Hz |
|
Interrupt Rating |
65 kAIC at 240 Vac |
|
|
14 kAIC at 480Y/277 Vac |
|
Number of Poles |
Three-pole |
Information About GHB3070
The GHB3070, manufactured by Eaton, is a member of the Series C complete molded case circuit breaker lineup. It features a G-frame design and is identified by the model designation GHB. This circuit breaker is classified as a complete breaker, offering both fixed thermal and fixed magnetic trip types for reliable operation. It is configured as a three-pole unit with an amperage rating of 70A.
Designed for a wide range of applications, the GHB3070 is suitable for electrical systems operating at voltages of 480Y/277 Vac and 125/250 Vdc, accommodating both alternating current (AC) and direct current (DC) environments. Its frequency rating spans 50/60 Hz, ensuring compatibility with various power systems.
With its robust construction, the GHB3070 is engineered to provide durable and dependable performance in demanding electrical environments. The molded case construction ensures enhanced protection and reliability, making it suitable for industrial and commercial applications where continuous operation is essential.
Featuring a G-frame design, this circuit breaker is built to withstand high levels of electrical stress while maintaining stable and consistent performance. The fixed thermal and fixed magnetic trip types ensure precise and reliable circuit protection under varying load conditions, minimizing the risk of damage to connected equipment and ensuring the safety of personnel.
Manufacturer information
Eaton Corporation is a multinational power management company offering a diverse range of electrical, hydraulic, and aerospace solutions. Known for innovation, Eaton serves customers in various industries worldwide.
