GKMC06 | Honeywell MICRO SWITCH GKM Series Key Operated Safety Interlock Switch
- Regular price
- $299.00
- Sale price
- $299.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: GKMC06
Description
The Honeywell MICRO SWITCH GKMC06 is a miniature key-operated safety interlock switch designed to ensure machine shutdown when protective guards are opened. Featuring 2 normally closed direct-opening contacts and a slow-action mechanism, it provides reliable safety performance in compact machinery applications. The GKMC06 is engineered for use on hinged or sliding guards where controlled access and operator protection are critical.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell MICRO SWITCH |
| Category | Safety Switches |
| Part Number | GKMC06 |
| Subcategory | Key Operated Safety Interlock Switches |
| Product Type | Key Operated Safety Interlock Switch |
| Series | GKM |
| Actuator Type | Key (sold separately) |
| Contact Configuration | 2 NC |
| Switching Action | Direct Opening, Slow Action |
| Contact Material | Silver Nickel |
| Termination Type | Side Exit M12 DC Micro-change Connector |
| Rated Current | 100 mA to 10 A (Thermal) |
| Rated Voltage | 240 Vac / 250 Vdc Max |
| Housing Material | Plastic |
| Sealing Rating | IP66 / IP67 |
| Operating Temperature | −25°C to +85°C |
| Mechanical Life | 5 Million Operations |
| Certifications | UL, CE, SIL 3 Capable |
| Weight | Approx. 0.4 lb (0.18 kg) |
Information About GKMC06
The GKMC06 is part of the Honeywell MICRO SWITCH GKM Series of global miniature safety key interlock switches. It is built with a compact plastic housing and silver-nickel contacts to support durable operation in confined industrial environments. The switch is intended for use on machinery doors, covers, and enclosures where key removal forces the system into a safe state. Designed to meet international safety requirements, it supports SIL 3 capable systems and integrates easily through an M12 micro-change connector interface.
Key Features:
- Key-Operated Safety Interlock: Ensures machine operation is disabled when the key is removed from the guard.
- 2NC Direct-Opening Contacts: Provides positive opening for enhanced functional safety compliance.
- Slow-Action Switching Mechanism: Delivers controlled and reliable contact operation.
- Compact Plastic Housing: Suitable for small enclosures and space-constrained installations.
- Side Exit M12 Connector: Allows quick, secure electrical connection using micro-change cabling.
- High Electrical Rating: Supports switching currents from 100 mA up to 10 A (thermal).
- Environmental Sealing: Rated IP66/67 for resistance to dust and water ingress.
The GKMC06 delivers the reliability and precision required for machine guarding and industrial safety interlock applications.
