GLC-FE-100BX-U | Cisco Optical Transceiver
- Regular price
- $137.00
- Sale price
- $137.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: GLC-FE-100BX-U
Description
The Cisco GLC-FE-100BX-U is a 100BASE-BX-U Fast Ethernet SFP transceiver module designed for single-strand fiber deployments.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Cisco |
| Category |
PLCs/Machine Control
|
| Part Number | GLC-FE-100BX-U |
| Subcatecory |
PLC Module/Rack
|
|
Media Type
|
Single-Mode Fiber (SMF) |
|
TX Wavelength
|
1310 nm. |
|
RX Wavelength
|
1550 nm. |
|
Minimum Optical Budget
|
17 dB |
|
Maximum Distance
|
15km |
|
Supported Data Rate
|
100-155Mbps |
|
Supported Applications
|
100M Ethernet (100Mbps), STM-1 (155Mbps) |
|
DDM/DOM
|
Support |
|
Temperature Range
|
Standard 0°-70°C |
|
Connectors
|
Single LC |
|
Form Factor
|
Plug-in module |
|
Interfaces
|
1 x Ethernet 100Base-BX - LC single-mode |
|
Compatible
Slots |
1 x SFP (mini-GBIC) |
|
Connectivity
Technology |
Wired |
|
Cabling
Type |
100Base-BX |
|
Data Link
Protocol |
100Mb LAN |
|
Width
|
0.5 in |
|
Depth
|
2.2 in |
|
Height
|
0.3 in |
|
Min
Operating Temperature |
32 °F |
|
Max
Operating Temperature |
122 °F |
|
Weight
|
0.03 kgs |
Information About GLC-FE-100BX-U
The Cisco GLC-FE-100BX-U is a compact, high-performance Fast Ethernet SFP transceiver module designed to provide efficient, bidirectional fiber connectivity for Cisco switches and routers. It enables reliable data transmission over single-mode fiber using a single strand, making it ideal for enterprise, metro access, and service provider network deployments requiring cost-effective and long-distance communication.
Key Features:
- Type: 100BASE-BX-U Fast Ethernet SFP transceiver supporting 100 Mbps data rates
- Supported Devices: Compatible with Cisco switches and routers equipped with SFP ports supporting Fast Ethernet
- Functionality: Provides bidirectional data transmission using a single fiber strand (1310 nm transmit / 1550 nm receive) with a reach of up to 10 kilometers
- Form Factor: Compact SFP design for flexible deployment and hot-swappable installation
- Installation: Easy plug-and-play integration with LC connector interface; compatible with matching downstream transceiver (GLC-FE-100BX-D)
- Construction: Built for consistent, long-term performance in enterprise and service provider environments
The GLC-FE-100BX-U is an ideal solution for organizations seeking reliable, space-saving fiber connectivity to extend network reach and reduce cabling infrastructure costs.
