Goulds CentriPro S10020N1 Simplex Indoor Pump Control Panel 115/230 Volt 20 Ampere
- Regular price
- $1,199.00
- Sale price
- $1,199.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: S10020N1
Description
The Goulds CentriPro S10020N1 is a simplex indoor pump control panel designed to automatically control a single pump in wastewater, sewage, effluent, sump, and water-transfer applications. It operates with 115- or 230-volt single-phase power, supports pump loads up to 20 amperes, and incorporates operating controls and a high-level alarm system within a NEMA 1 steel enclosure.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Goulds CentriPro |
| Category | Pump Controls |
| Part Number | S10020N1 |
| Subcategory | Simplex Pump Control Panel |
| Product Type | Indoor Simplex Liquid Level and Pump Control Panel |
| Number of Pumps Controlled | 1 |
| Voltage | 115 or 230 volts alternating current, field adjustable |
| Phase | Single Phase |
| Frequency | 60 hertz |
| Pump Current Range | 0–20 amperes |
| Enclosure Rating | NEMA 1 |
| Enclosure Material | Steel |
| Enclosure Dimensions | 8 × 8 × 4 inches, excluding 3-inch warning light |
| Alarm Horn Rating | 95 decibels |
| Warning Light | 30-watt flashing red light |
| Control Functions | Hand-Off-Automatic Pump Control, Control On-Off, Alarm Silence, and Alarm Test |
| Alarm Interface | Auxiliary Contacts for Remote Alarm Connection |
| Certifications | UL and CUL Listed |
| Weight | 9.00 lbs |
Information About S10020N1
The S10020N1 is a Goulds CentriPro simplex control panel from the CentriPro wastewater control product family for indoor single-pump installations. Its steel enclosure contains the magnetic pump contactor, control circuitry, numbered screw terminals, operating switches, alarm horn, flashing warning light, and auxiliary alarm contacts required for automatic pump management. The panel is field adjustable for either 115 or 230 volts at 60 hertz and can use a common power feed for the pump and control circuit or separate feeds to maintain alarm operation if the pump circuit breaker trips. It uses externally connected float switches to determine liquid level and initiate pump and high-level alarm functions, with the required float switches selected separately according to the installation.
Key Features:
- Simplex Pump Control: Controls one pump automatically according to liquid-level signals received from externally connected float switches.
- Dual-Voltage Configuration: Field adjustable for 115- or 230-volt single-phase operation at 60 hertz.
- 20-Ampere Capacity: Designed for single-phase pump applications requiring up to 20 amperes.
- Hand-Off-Automatic Control: Includes a through-door pump selector for manual operation, shutdown, or automatic level-based pump control.
- High-Level Alarm: Incorporates a 95-decibel alarm horn, 30-watt flashing red warning light, test control, and manual silence function.
- Auxiliary Alarm Contacts: Provides contacts for connection to a remote alarm or monitoring circuit.
- Flexible Power Wiring: Supports either a single electrical feed or separate pump and control-circuit feeds to preserve alarm operation during a pump breaker trip.
- Indoor Steel Enclosure: Uses a NEMA 1 steel enclosure intended for dry indoor installations and is not designed for outdoor or weather-exposed locations.
The S10020N1 delivers the reliability and precision required for automatic single-pump operation, liquid-level management, and high-level alarm supervision in indoor wastewater and water-transfer systems.
