GRX-3102-AU | Lutron GRAFIK Eyeยฎ 2-Zone Preset Lighting Control, 220โ240โฏV
- Regular price
- $996.00
- Sale price
- $996.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: GRX-3102-AU
Descriptionย
The GRX-3102-AU is a 2-zone preset lighting control unit in Lutronโs GRAFIK Eyeยฎ 3000 Series designed for controlling lighting zones with configurable presets. It is suited for 220โ240โฏV electrical systems common in Australia and other AU-region installations and offers reliable performance for small-scale architectural lighting control.
ย
ย
Technical Specificationsย
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Lutron |
| Category |
Preset Dimming Control Systems
|
| Part Number | GRX-3102-AU |
| Subcategory | 2โZone Architectural Lighting Control Unit |
| Series | GRAFIK Eyeยฎ 3000 Series |
| Input Power | 220โ240โฏV AC, 50/60โฏHz |
| Zone Capacity | 1,200โฏVA per zone |
| Unit Total Capacity | 1,600โฏVA |
| Number of Zones | 2 |
| Load Types | Incandescent, magnetic LV, neon/cold cathode, ELV transformer, HID |
| Preset Scenes | 4 onboard + 12 via wallstation/control interface |
| Fade Time Range | Instant to 60 minutes |
| Power-Failure Memory | Yes |
| Wiring Connections | Class 2/PELV low-voltage control wiring |
| Wallstation/Interface Capacity | Up to 8 control units, up to 16 control points |
| Surge/ESD Protection | IEC 61000โ4โ2, ANSI/IEEE C62.41 |
| Dimensions (WxHxD) | 141โฏmm ร 116โฏmm ร 57โฏmm (5.56โณ ร 4.56โณ ร 2.25โณ) |
| Required Wallbox | Twoโgang, โฅ89โฏmm deep |
| Operating Temp/Humidity | 0โ40โฏยฐC, โค90% nonโcondensing |
| Weight | ~1.3โฏlbs |
ย ย
ย
Information About GRX-3102-AU
The GRX-3102-AU is a 2-zone control unit for preset lighting scenes, delivering up to 1,200โฏW/VA per zone and a combined capacity of 1,600โฏW/VA at 220โ240โฏV input power. It supports direct switching and dimming of incandescent, magnetic low-voltage, neon/cold cathode, and ELV transformer loads; HID loads also supported. Installation requires a twoโgang wallbox with at least 89โฏmm depth and operates within standard ambient indoor conditions. The unit includes builtโin fade timing, powerโfailure memory, and connects via Classโฏ2 (PELV) wiring to wallstations and control interfaces.
Key Features:
- DualโZone Control: Manages up to two independent lighting zones with individual control.
- High Power Handling: Supports 1,200โฏW/VA per zone; 1,600โฏW/VA total per unit on 220โ240โฏV systems.
- Preset Scenes: Offers four onboard preset scenes plus off, with room for twelve additional scenes via external wallstations or interfaces.
- Smooth Fade Transitions: Adjustable fade times from immediate up to 60 minutes per scene.
- Power-Failure Memory: Automatically restores lights to previous levels and retains scene settings during outages.
- Direct Load Compatibility: Handles incandescent, magnetic low-voltage, neon/cold cathode, ELV systems, and HID loads.
- Robust Electrical Standards: Meets IEC and ANSI/IEEE surge and ESD standards for reliable operation.
- Compact Mounting Form: Fits standard two-gang wallbox with minimal spacing requirements.
The GRX-3102-AU delivers the reliability and precision required for compact, preset-based lighting control in architectural or residential environments.
