GRX-3503-T-AU-WH | Lutron Grafik Eye 3000 Series 3-Zone Control Unit 230V White
- Regular price
- $1,215.00
- Sale price
- $1,215.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: GRX-3503-T-AU-WH
Description
The Lutron GRX-3503-T-AU-WH Grafik Eye 3000 Series Control Unit is a three-zone lighting controller designed for managing preset lighting scenes in architectural and commercial environments. Operating on 230 VAC, this unit allows users to adjust and recall lighting levels across multiple zones, providing smooth, coordinated control for energy efficiency and occupant comfort.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Lutron |
| Category | Lighting Control |
| Part Number | GRX-3503-T-AU-WH |
| Subcategory | Control Units |
| Series | Grafik Eye 3000 |
| Zones Supported | 3 independent lighting zones |
| Voltage Rating | 230 VAC, 50/60 Hz |
| Control Type | Scene-based dimming control |
| Load Compatibility | Incandescent, halogen, fluorescent, and LED (depending on ballast/driver) |
| Mounting Type | Wall mount |
| User Interface | Sliders and scene selection buttons |
| Communication Link | GRX Link (for integration with wallstations or additional Grafik Eye units) |
| Scene Storage | Up to 16 programmable scenes |
| Color/Finish | White (WH) |
| Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Housing Material | Thermoplastic enclosure |
| Integration Compatibility | Lutron sensors, shades, and control systems |
| Standards Compliance | UL, NOM, FCC, CE (AU version) |
| Dimensions (H × W × D) | 4.75 in × 9.25 in × 1.88 in (approx.) |
| Application | Commercial, architectural, and residential lighting control |
| Weight | 1.4 lb (approx.) |
Information About GRX-3503-T-AU-WH
The GRX-3503-T-AU-WH is part of Lutron’s Grafik Eye 3000 Series, an advanced lighting control platform designed for multi-zone dimming and scene-based automation. This model supports three individually controlled zones, each capable of independent brightness adjustment or preset recall. The unit integrates with Lutron’s GRX communication link, allowing centralized control or networking with multiple Grafik Eye controllers. Its 230V AU-rated configuration makes it suitable for international installations, while the wall-mounted design and sleek white finish complement modern interiors in offices, hospitality, and residential spaces.
Key Features:
- Three-Zone Control: Independently controls three lighting zones for precise scene configuration.
- Preset Scene Selection: Stores and recalls multiple lighting scenes for different activities or moods.
- 230V Operation: Designed for international voltage standards, suitable for Australian and EU markets.
- Network Integration: Connects via GRX link to expand system capability with additional control units or wallstations.
- User-Friendly Interface: Includes slider controls and backlit scene buttons for intuitive operation.
- Energy Efficient: Enables dimming-based energy savings while maintaining occupant comfort.
- Architectural Design: Slim, modern wall-mounted design in gloss white finish.
- System Compatibility: Works with occupancy sensors, daylight sensors, and Lutron integration devices.
The GRX-3503-T-AU-WH delivers the reliability and precision required for professional-grade, programmable multi-zone lighting control.
