Product Description P/N: GWF-7075B
Description
The Gamewell-FCI GWF-7075B is an intelligent addressable fire alarm control panel housed in a black cabinet. It supports both wired Velociti devices and SWIFT wireless expansion, featuring dual NACs, a four-line LCD, and built-in IP communications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Gamewell-FCI |
| Category | Fire Alarm Systems |
| Part Number | GWF-7075B |
| Subcategory | Fire Alarm Control Panels |
| Type | Intelligent Addressable Fire Alarm Control Panel |
| Cabinet Color | Black |
| Display | Four-line LCD, 40 characters per line |
| SLC Capacity | 75 detectors + 75 modules (Velociti protocol) |
| Wireless Support | Up to 4 SWIFT gateways, 49 devices per gateway |
| NAC Circuits | 2 configurable NACs, 1 A per NAC, 2.5 A system total |
| Wiring Classes | Class A (Style 6/7) and Class B (Style 4) for SLC and SBUS |
| Communications | Dual-line DACT with IP reporting; optional cellular add-on |
| Programming | USB interface, JumpStart auto programming, front-panel programming |
| Primary Power | 120 VAC, 60 Hz |
| Battery Support | 7–35 Ah; 7 Ah max internal, larger capacity with external cabinet |
| Dimensions | 19 × 17 × 4 in |
| Weight | 16 lbs |
Information About GWF-7075B
The GWF-7075B is a compact intelligent addressable fire alarm control panel designed by Gamewell-FCI to support System Sensor Velociti protocol devices along with optional SWIFT wireless expansion. It includes one onboard SLC with capacity for up to 75 detectors and 75 modules, two configurable NACs, and flexible Class A or Class B wiring. Its built-in dual-line DACT with IP reporting and optional cellular module provide robust communication, while programming is simplified through USB connectivity, JumpStart auto setup, and front-panel configuration.
Key Features:
- Intelligent SLC capacity: The panel supports up to 75 addressable detectors and 75 addressable modules on its onboard SLC using the System Sensor Velociti protocol, allowing flexible system design for small to mid-sized facilities.
- Wireless integration: The GWF-7075B is fully compatible with SWIFT wireless technology, enabling connection of up to four wireless gateways, each managing 49 devices, which reduces wiring costs and simplifies installation in challenging areas.
- Clear LCD interface: A four-line, 40-character-per-line LCD provides real-time system status, event notifications, and programming details directly at the panel, ensuring quick access to vital information.
- Configurable NAC outputs: Two NACs are included, each rated at 1 amp, with a combined system current of 2.5 amps, supporting a wide range of notification appliances such as horns, strobes, and speakers.
- Advanced communication: The built-in dual-line Digital Alarm Communicator Transmitter (DACT) with IP reporting ensures reliable off-site monitoring, with an optional cellular module available for redundant communication paths.
- Flexible wiring options: The panel supports both Class A (Style 6/7) and Class B (Style 4) wiring for the SLC and SBUS, giving installers more choices to meet code requirements and system needs.
- Streamlined programming: USB connectivity and JumpStart auto programming minimize installation time, while front-panel programming enables field adjustments without additional software tools.
- Robust power and battery support: Operating on a primary 120 VAC input, the panel provides integrated charging for 7–35 Ah batteries (7 Ah max inside the cabinet, with larger capacity supported externally) to ensure system reliability during power outages.
The GWF-7075B delivers the reliability and precision required for professional fire protection, communication, and system scalability in commercial environments.
