H-6300-Q-H00AA | Allen-Bradley Brushless Servo Motor
- Regular price
- $9,259.00
- Sale price
- $9,259.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: H-6300-Q-H00AA
Description
The Allen-Bradley H-6300-Q-H00AA is a brushless, low-inertia servo motor from the H-Series, engineered for high-performance industrial automation applications. This motor is designed to deliver precise motion control and is compatible with Allen-Bradley ULTRA 200 and ULTRA Plus series drives.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Servo Products
|
| Part Number | H-6300-Q-H00AA |
| Subcategory |
Servo Motors
|
| Series Designator | Low Inertia |
| Frame Size | 6300 |
| Optical Encoder Line Count | 2000 |
| Options | Standard |
| Flange | Standard |
| Damping | 0.19 N·m/krpm |
| Friction Torque | 0.36 N·m |
| Voltage Rating (IEC) | 500 V AC/DC |
| Poles | 8 |
| Weight | 79.00 lbs |
Information About H-6300-Q-H00AA
The Allen-Bradley H-6300-Q-H00AA is a brushless, low-inertia servo motor from the H-Series, engineered for high-performance industrial applications requiring precise motion control.
Key Features:
-
Motor Type: Brushless AC Servo Motor
-
Frame Size: 6300
-
Power Rating: 6.8 HP (approximately 5.1 kW)
-
Maximum Speed: 3000 RPM
-
Voltage: 240 V
-
Current: 46 A
-
Encoder: 2000-line optical encoder
-
Poles: 8
-
Friction Torque: 0.36 N·m
-
Damping: 0.19 N·m/krpm
-
Thermal Resistance: 0.24 °C/W
-
Operating Temperature Range: 0°C to 40°C (32°F to 104°F)
-
Environmental Protection: IP65 (with optional shaft seal)
-
Mounting Flange: Standard
This servo motor is compatible with Allen-Bradley ULTRA 200 and ULTRA Plus series drives, making it suitable for applications such as CNC machinery, robotics, and automated manufacturing systems. Its robust design ensures reliable operation in demanding industrial environments.
Description
The Allen-Bradley H-6300-Q-H00AA is a brushless, low-inertia servo motor from the H-Series, engineered for high-performance industrial automation applications. This motor is designed to deliver precise motion control and is compatible with Allen-Bradley ULTRA 200 and ULTRA Plus series drives.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Allen-Bradley |
| Category |
Servo Products
|
| Part Number | H-6300-Q-H00AA |
| Subcategory |
Servo Motors
|
| Series Designator | Low Inertia |
| Frame Size | 6300 |
| Optical Encoder Line Count | 2000 |
| Options | Standard |
| Flange | Standard |
| Damping | 0.19 N·m/krpm |
| Friction Torque | 0.36 N·m |
| Voltage Rating (IEC) | 500 V AC/DC |
| Poles | 8 |
| Weight | 79.00 lbs |
Information About H-6300-Q-H00AA
The Allen-Bradley H-6300-Q-H00AA is a brushless, low-inertia servo motor from the H-Series, engineered for high-performance industrial applications requiring precise motion control.
Key Features:
-
Motor Type: Brushless AC Servo Motor
-
Frame Size: 6300
-
Power Rating: 6.8 HP (approximately 5.1 kW)
-
Maximum Speed: 3000 RPM
-
Voltage: 240 V
-
Current: 46 A
-
Encoder: 2000-line optical encoder
-
Poles: 8
-
Friction Torque: 0.36 N·m
-
Damping: 0.19 N·m/krpm
-
Thermal Resistance: 0.24 °C/W
-
Operating Temperature Range: 0°C to 40°C (32°F to 104°F)
-
Environmental Protection: IP65 (with optional shaft seal)
-
Mounting Flange: Standard
This servo motor is compatible with Allen-Bradley ULTRA 200 and ULTRA Plus series drives, making it suitable for applications such as CNC machinery, robotics, and automated manufacturing systems. Its robust design ensures reliable operation in demanding industrial environments.
