H8PS-16BF | Omron H8PS Series Cam Positioner 16-Output 24 VDC NPN LCD Display
- Regular price
- $1,954.00
- Sale price
- $1,954.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: H8PS-16BF
Description
The Omron H8PS-16BF Cam Positioner is a 16-output programmable positioning controller designed for precise synchronization of machine operations with rotary motion. Operating on a 24 VDC supply, it provides accurate timing and control with an easy-to-read 3-digit LCD display. This compact, surface-mount unit delivers reliable cam control in packaging, labeling, and automated production systems.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Omron |
| Category | Industrial Automation and Controls |
| Part Number | H8PS-16BF |
| Subcategory | Cam Positioners |
| Alternate Part Number | H8PS16BF |
| Series | H8PS Series |
| Type | Absolute Cam Positioner |
| Mounting Type | Surface Mount |
| Output Type | NPN |
| Number of Outputs | 16 |
| Display Type | 3-Digit LCD Display |
| Supply Voltage | 24 VDC |
| Power Consumption | Approx. 10 W (typical for H8PS series) |
| Termination Style | Screw Terminals |
| Control Function | Programmable cam position and timing output |
| Input Type | Encoder / Position Feedback (depending on configuration) |
| Enclosure Color | Light Gray |
| Operating Temperature Range | 0°C to +55°C |
| Storage Temperature Range | -20°C to +65°C |
| Protection Rating | IP20 (panel-mounted applications) |
| Compliance Standards | CE, UL, cUL Listed |
| Weight | Approx. 0.35 kg (0.77 lb) |
Information About H8PS-16BF
The H8PS-16BF is part of Omron’s H8PS Series of cam positioners, built to simplify rotary position control in industrial automation environments. It operates on a 24 VDC power supply and features NPN transistor outputs, providing precise and responsive output signals based on encoder position feedback. The front-facing 3-digit LCD display enables easy configuration and monitoring of cam settings and angles. Designed for long-term reliability, this absolute-type positioner ensures stable, repeatable performance for motor-driven machinery and high-speed control applications.
Key Features:
- 16-Output Cam Positioner: Enables precise synchronization of machine motion and events.
- 24 VDC Power Input: Provides stable operation in control panels and automated systems.
- NPN Output Configuration: Compatible with standard transistor control circuits.
- 3-Digit LCD Display: Simplifies setup, monitoring, and adjustment of cam timing.
- Absolute Type Control: Maintains exact position data even after power cycling.
- Compact Mounting Design: Surface-mount configuration saves space in control panels.
- Screw Terminal Connections: Ensures secure and reliable wiring for industrial environments.
- Omron H8PS Series Reliability: Proven precision for high-speed and repetitive operations.
The H8PS-16BF delivers the reliability and precision required for rotary motion control, cam timing, and machine synchronization in automated production lines.
