Product Description P/N: HDL36100

Description / Specifications

Description

The HDL36100 PowerPacT H-Frame circuit breaker is engineered to safeguard electrical systems from overload and short circuit damage. Available with both thermal magnetic and Micrologic electronic trip units, it ensures comprehensive circuit protection. Featuring a thermal magnetic trip unit, this circuit breaker offers a robust breaking capacity of 14kA at 600VAC, effectively mitigating potential electrical faults. Equipped with dual-break rotating contacts, it minimizes peak current during short circuit events, enhancing operational reliability.



Technical Specifications

Part #

HDL36100

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Range

PowerPact

Product name

PowerPact H

Product or Component Type

Circuit breaker

Device Application

Distribution Line

Rated Current

100 A

Number of Poles

3P

Protected Poles Description

3t

Control Type

Toggle

Breaking Capacity Code

D

Rated Operational Voltage ([Ue])

690 V AC 50/60 Hz IEC 60947-3

Network Frequency

50/60 Hz

Rated Impulse Withstand Voltage ([Uimp])

8 kV IEC 60947-2

Trip Unit Technology

Thermal-magnetic

Magnetic Tripping Current

1700 A

Magnetic Hold Current

900 A

Continuous Current Rating

80 %

Rated Insulation Voltage ([Ui])

750 V IEC 60947-2

Suitability for Isolation

Yes IEC 60947-2

Utilisation Category

Category A

AWG Gauge

AWG 14...AWG 3/0 aluminium/copper terminal

Local Signalling

Switched off (OFF), 1 trip indicator (green)

Mounting Mode

Unit mount lug

Mounting Support

Lug

Power Wire Stripping Length

0.63 in (16 mm)

Color

Black

Height

6.42 in (163 mm)

Width

4.09 in (104 mm)

Depth

3.39 in (86 mm)

Net Weight

4.85 lb(US) (2.2 kg)






Information About HDL36100

The HDL36100 circuit breaker, part of the PowerPacT H-Frame series, is engineered to safeguard electrical systems from the risks associated with overloads and short circuits. Available with options for both thermal magnetic and Micrologic electronic trip protection units, this breaker ensures robust circuit protection. Specifically, the thermal magnetic variant of this PowerPacT H-Frame circuit breaker delivers circuit protection by means of a thermal magnetic trip unit, providing a substantial breaking capacity of 14kA at 600VAC.

Designed with dual-break rotating contacts, these breakers effectively minimize the peak current flow during short circuit faults, thereby enhancing operational safety and reliability. Each PowerPacT H-Frame circuit breaker includes an integral push-to-trip button integrated into its cover, facilitating manual tripping of the breaker when necessary.

Offered in configurations suitable for both 2-pole and 3-pole unit mount and I-Line installations, this particular model features lugs on both the line and load sides, ensuring versatile application possibilities within electrical distribution setups.

The HDL36100 breaker is specifically rated for 100A across its three poles, with a consistent breaking capacity of 14kA at 600VAC, underlining its suitability for demanding industrial and commercial environments. It maintains a continuous current rating of 80%, supporting sustained operational efficiency under load.
