HDL36150 | Schneider Electric Circuit Breaker
- Regular price
- $789.00
- Sale price
- $789.00
- Regular price
-
Couldn't load pickup availability
Do you need more quantity?
Product Description P/N: HDL36150
Description
The HDL36150 is a 3-pole circuit breaker from the PowerPact H series by Schneider Electric, designed to protect electrical systems against overloads and short circuits. It features thermal magnetic trip technology with a breaking capacity of 14,000 amps (14kA) at 600VAC, ensuring effective protection under fault conditions.
Equipped with dual-break rotating contacts, the HDL36150 reduces peak current during short circuit faults, thereby enhancing operational safety and reliability. It includes an integral push-to-trip button on the cover for manual circuit interruption, facilitating maintenance procedures.
Technical Specifications
|
Part # |
HDL36150 |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Range |
PowerPact |
|
Product name |
PowerPact H |
|
Product or Component Type |
Circuit breaker |
|
Device Application |
Distribution Line |
|
Rated Current |
150 A |
|
Number of Poles |
3P |
|
Protected Poles Description |
3t |
|
Control Type |
Toggle |
|
Breaking Capacity Code |
D |
|
Rated Operational Voltage [Ue] |
690 V AC 50/60 Hz |
|
Network Frequency |
50/60 Hz |
|
Rated Impulse Withstand Voltage [Uimp] |
8 kV |
|
Trip Unit Technology |
Thermal-magnetic |
|
Magnetic Tripping Current |
1700 A |
|
Magnetic Hold Current |
900 A |
|
Continuous Current Rating |
80 % |
|
Rated Insulation Voltage [Ui] |
750 V |
|
Suitability for Isolation |
Yes |
|
Utilisation Category |
Category A |
|
AWG Gauge |
AWG 14...AWG 3/0 aluminium/copper terminal |
|
Local Signalling |
Switched off (OFF) 1 trip indicator (green) |
|
Power Wire Stripping Length |
0.63 in (16 mm) |
|
Color |
Black |
|
Height |
6.42 in (163 mm) |
|
Width |
4.09 in (104 mm) |
|
Depth |
3.39 in (86 mm) |
|
Net Weight |
4.85 lb (2.2 kg) |
Information About HDL36150
The HDL36150 is a 3-pole circuit breaker from Schneider Electric's PowerPact H series, specifically engineered to safeguard electrical systems against overloads and short circuits. Operating at 600VAC, it utilizes thermal magnetic trip technology, offering a substantial breaking capacity of 14,000 amps (14kA). This ensures effective protection under fault conditions, mitigating potential damage to electrical components.
Key features of the PowerPact H-Frame circuit breakers include dual-break rotating contacts, designed to minimize peak current during short circuit faults. This design enhances operational safety by reducing stress on the electrical system during fault conditions. Additionally, all PowerPact H-Frame circuit breakers are equipped with an integral push-to-trip button on the cover, facilitating manual tripping for maintenance and safety procedures.
The HDL36150 model includes lugs on both the line and load sides, ensuring secure electrical connections in distribution applications. It supports a continuous current rating of 150A at 80%, making it suitable for sustained operational demands in industrial and commercial environments where reliable performance is essential.
