Part #: HF-KP43 Manufactured by: Mitsubishi
Regular price
$217.00
Sale price
$217.00
Regular price
2 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
Mitsubishi Electric developed the HF-KP43, an AC brushless rotary servo motor part of the HF-KP series.
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: HF-KP43
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Mitsubishi
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: HF-KP43

Description / Specifications

Description

The Mitsubishi HF-KP43 is a reliable and efficient 400W AC servo motor with a rated rotational speed of 3000 rpm. Known for its accurate and consistent performance, it features an 18-bit resolution absolute encoder, ensuring exceptional precision and repeatability. The motor comes with a straight shaft and is IP65 rated, making it resistant to dust and water. It utilizes a 60x60mm flange mounting mode and operates within a temperature range of 0 to 40 degrees Celsius, making it suitable for various industrial applications.



Technical Specifications



Brand Mitsubishi
Part Number HF-KP43
Category Servo Products
Subcategory Servo Motor
Series MELSERVO J3 (HF-KP) series
Product Type AC servo motor
Motor type Low inertia/Small capacity
Supply voltage 200V AC class
Rated current 2.7amps
Rated active power 400W / 0.4kW
Rotational speed 3000rpm; 6000rpm (maximum)
Torque 1.3Nm nominal; Maximum 3.8Nm
Moment of inertia 0.000042kg.m2 (0.42kg.cm2)
Power rate at continuous rated torque 38.6 kW/s
Shaft shape Standard straight shaft
Mounting mode 60x60mm flange mounting
Degree of protection IP65





Information About HF-KP43

The Mitsubishi Electric HF-KP43 is an AC brushless rotary servo motor in the HF-KP series, characterized by its low inertia and small capacity, making it ideal for precise motion control applications. With a rated power output of 0.4 kW (400 watts), it is suitable for a variety of industrial automation tasks. The motor delivers a rated torque of 1.3 Nm and a maximum torque of 3.8 Nm, allowing it to handle variable load conditions effectively. Its rated rotational speed is 3000 RPM, with a maximum speed of 6000 RPM, ensuring quick responses and efficient control due to its low inertia.

The HF-KP43 has a rated current of 2.7 amps and a maximum current of 8.1 amps, providing ample power for demanding applications. It operates continuously at its rated torque with a power rate of 38.6 kW/s, indicating its ability to maintain high power output consistently. The motor features a standard straight shaft without an electromagnetic brake or shaft keyway, ensuring compatibility with various mechanical systems.

The HF-KP43 is IP65 rated, making it resistant to dust and moderate water exposure, suitable for harsh industrial environments. This level of protection ensures the motor's reliability and longevity. Overall, the HF-KP43 offers a balanced combination of power, speed, and inertia, making it well-suited for industrial applications that require precise and adaptable motion control.




Manufacturer information

Mitsubishi Electric Corporation, established in 1921, is a leading global manufacturer of electrical and electronic products. Renowned for innovation, it specializes in automation, energy, and electronic systems, contributing to advancements across various industries worldwide.

IQElectro is not an authorized distributor.
QElectro LLC (IQElectro) is NOT an Authorized Distributor or in any way affiliated with Rockwell Automation, Siemens, or any other Manufacturers. IQElectro is NOT an Authorized Dealer of this product. The product may be of older version, date codes, or design than that available from authorized dealers. As IQElectro is not an authorized dealer of this product, the Original Manufacturer's Warranty and Support DO NOT apply. IQElectro sells SURPLUS only and DOES NOT SELL SOFTWARE or FIRMWARE licenses For more detailed information, please refer to the full version of our disclaimer policy Disclaimer Policy.
Description / Specifications

Description

The Mitsubishi HF-KP43 is a reliable and efficient 400W AC servo motor with a rated rotational speed of 3000 rpm. Known for its accurate and consistent performance, it features an 18-bit resolution absolute encoder, ensuring exceptional precision and repeatability. The motor comes with a straight shaft and is IP65 rated, making it resistant to dust and water. It utilizes a 60x60mm flange mounting mode and operates within a temperature range of 0 to 40 degrees Celsius, making it suitable for various industrial applications.



Technical Specifications



Brand Mitsubishi
Part Number HF-KP43
Category Servo Products
Subcategory Servo Motor
Series MELSERVO J3 (HF-KP) series
Product Type AC servo motor
Motor type Low inertia/Small capacity
Supply voltage 200V AC class
Rated current 2.7amps
Rated active power 400W / 0.4kW
Rotational speed 3000rpm; 6000rpm (maximum)
Torque 1.3Nm nominal; Maximum 3.8Nm
Moment of inertia 0.000042kg.m2 (0.42kg.cm2)
Power rate at continuous rated torque 38.6 kW/s
Shaft shape Standard straight shaft
Mounting mode 60x60mm flange mounting
Degree of protection IP65





Information About HF-KP43

The Mitsubishi Electric HF-KP43 is an AC brushless rotary servo motor in the HF-KP series, characterized by its low inertia and small capacity, making it ideal for precise motion control applications. With a rated power output of 0.4 kW (400 watts), it is suitable for a variety of industrial automation tasks. The motor delivers a rated torque of 1.3 Nm and a maximum torque of 3.8 Nm, allowing it to handle variable load conditions effectively. Its rated rotational speed is 3000 RPM, with a maximum speed of 6000 RPM, ensuring quick responses and efficient control due to its low inertia.

The HF-KP43 has a rated current of 2.7 amps and a maximum current of 8.1 amps, providing ample power for demanding applications. It operates continuously at its rated torque with a power rate of 38.6 kW/s, indicating its ability to maintain high power output consistently. The motor features a standard straight shaft without an electromagnetic brake or shaft keyway, ensuring compatibility with various mechanical systems.

The HF-KP43 is IP65 rated, making it resistant to dust and moderate water exposure, suitable for harsh industrial environments. This level of protection ensures the motor's reliability and longevity. Overall, the HF-KP43 offers a balanced combination of power, speed, and inertia, making it well-suited for industrial applications that require precise and adaptable motion control.




Manufacturer information

Mitsubishi Electric Corporation, established in 1921, is a leading global manufacturer of electrical and electronic products. Renowned for innovation, it specializes in automation, energy, and electronic systems, contributing to advancements across various industries worldwide.
