HFD1030L | Eaton Cutler-Hammer 30A 1-Pole Molded Case Circuit Breaker 277VAC 65kA
- Regular price
- $418.00
- Sale price
- $418.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HFD1030L
Description
The Eaton Cutler-Hammer HFD1030L is a single-pole molded case circuit breaker designed for reliable overcurrent and short-circuit protection in industrial and commercial power systems. This 30-amp, 277-volt unit from Eaton’s Series C line provides thermal-magnetic trip protection and a high interrupting capacity of 65 kA at 277 VAC. Built with a compact F-frame design, the HFD1030L ensures dependable circuit protection for heavy-duty applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton Cutler-Hammer |
| Category | Circuit Breaker |
| Part Number | HFD1030L |
| Subcategory | Molded Case |
| Series | Series C |
| Type | HFD |
| Frame Type | F Frame |
| Poles | 1 |
| Amperage Rating | 30A |
| Voltage Rating | 277 VAC / 125 VDC |
| Interrupting Capacity | 65 kA @ 277 VAC |
| Trip Type | Fixed Thermal / Fixed Magnetic |
| Connection Type | Feed-Thru |
| Frequency | 50/60 Hz |
| Functions | LI – Long-Time and Instantaneous Trip |
| Temperature Rating | -25°C to 70°C (-13°F to 158°F) |
| Certifications | UL Listed, CSA Approved |
| Dimensions (H x W x D) | 6 in x 1.38 in x 3.38 in |
| Country of Origin | Dominican Republic |
| Weight | 4.5 lb |
Information About HFD1030L
The HFD1030L is part of Eaton’s Series C line of molded case circuit breakers, engineered for consistent performance and broad compatibility with electrical panels and OEM equipment. It features a fixed thermal and fixed magnetic trip mechanism that provides precise long-time and instantaneous trip functions. Designed with a feed-thru connection and an F-frame housing, the breaker supports 50/60 Hz operation and withstands demanding industrial environments. The HFD1030L is UL Listed and CSA Approved, ensuring compliance with international safety standards for electrical distribution systems.
Key Features:
- Amperage Rating: 30A current capacity suitable for medium-load protection applications.
- Voltage Rating: Rated for up to 277 VAC and 125 VDC operation.
- Interrupting Capacity: High fault interruption rating of 65 kA at 277 VAC for enhanced system safety.
- Trip Type: Fixed thermal and fixed magnetic trip provides dependable overload and short-circuit protection.
- Frame Design: Compact F-frame ensures compatibility with a variety of panelboard configurations.
- Connection Type: Feed-thru terminal connection simplifies installation and wiring.
- Operating Temperature Range: Performs reliably in environments from -25°C to 70°C (-13°F to 158°F).
- Certifications: UL Listed and CSA Approved for verified quality and performance.
The HFD1030L delivers the reliability and precision required for industrial-grade circuit protection and power distribution systems.
