HFD2175 | Eaton 175A 2-Pole 600V Series C F-Frame Thermal Magnetic Molded Case Circuit Breaker
- Regular price
- $1,399.00
- Sale price
- $1,399.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HFD2175
Description
The Eaton HFD2175 is a 2-pole molded case circuit breaker engineered for dependable circuit protection in commercial and industrial power systems. Rated for 175 amps and 600 VAC, it provides thermal magnetic protection against overloads and short circuits. With an interrupting capacity of up to 100 kA at 240 VAC and 65 kA at 480 VAC, the breaker ensures safe, efficient power distribution in demanding electrical environments.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breakers |
| Part Number | HFD2175 |
| Subcategory | Molded Case Circuit Breakers |
| Series | Series C |
| Frame Type | F Frame |
| Amperage Rating | 175 A |
| Voltage Rating | 600 VAC / 250 VDC |
| Interrupting Rating | 100 kA @ 240 VAC, 65 kA @ 480 VAC, 25 kA @ 600 VAC |
| Trip Type | Thermal Magnetic |
| Functions | Long-Time and Instantaneous Trip |
| Number of Poles | 2 |
| Mounting Type | Panel Mount / Bolt-On |
| Connection Type | Bolt-On Line / Load Side Lug |
| Frequency Rating | 50/60 Hz |
| Certifications | UL Listed, CSA Approved, CE Compliant |
| Operating Temperature | 40°C |
| Dimensions (HxWxD) | 5 in x 3.5 in x 7.5 in |
| Weight | 3 lb |
Information About HFD2175
The HFD2175 is part of Eaton’s Series C F-Frame molded case circuit breaker line, offering reliable performance and compatibility with a wide range of panel systems. Designed for panel mounting with a bolt-on connection, it supports load-side lug terminals for secure electrical contact. The breaker features long-time and instantaneous trip functions for precise overload and fault response, maintaining system protection under varying load conditions. Certified under UL, CSA, and CE standards, the HFD2175 ensures compliance with international safety requirements for industrial and commercial applications.
Key Features:
- Amperage Rating: Supports 175A continuous current for medium-duty electrical systems.
- Voltage Rating: Operates at 600 VAC and 250 VDC for flexible installation options.
- Interrupting Capacity: 100 kA @ 240 VAC and 65 kA @ 480 VAC for enhanced short-circuit protection.
- Trip Type: Thermal magnetic trip for both long-time and instantaneous protection.
- Mounting Type: Bolt-on configuration for stable, panel-mounted installations.
- Frame Type: F-frame molded case design for compact, durable performance.
- Certifications: UL Listed, CSA Approved, CE Compliant for global use.
- Applications: Suitable for switchboards, panelboards, and industrial machinery protection.
The HFD2175 delivers the reliability and precision required for safe, efficient, and high-performance power distribution in commercial and industrial systems.
