Product Description P/N: HFD3070

Description / Specifications

Description

The HFD3070 is an Eaton Series C complete molded case circuit breaker. It belongs to the F-frame category, specifically the HFD series. This circuit breaker features fixed thermal and fixed magnetic trip types. It is a three-pole device with a current rating of 70 A. The voltage ratings are 600 Vac and 250 Vdc. This breaker is designed for load side connections and operates at a frequency of 50/60 Hz.



Technical Specifications



Part Number

HFD3070

Manufacturer

Eaton Cutler-Hammer

Family

Series C

Poles

3

Amps

70

Volts

600

Phase

3

Category

Molded Case / 3-Pole

Connection

Feed Thru

Type

HFD

Functions

LI - Long-Time and Instantaneous Trip

Protection

Thermal Magnetic

AIC Ratings

65kA@480V

Frame Type

F Frame



Information About HFD3070

The HFD3070 is a component of Eaton's Series C complete molded case circuit breakers. It falls under the F-frame classification within the HFD series. This circuit breaker is designed with fixed thermal and fixed magnetic trip types, ensuring reliable protection and operational efficiency in various electrical systems.

Key specifications of the HFD3070 include its three-pole configuration, which allows it to manage three distinct electrical circuits simultaneously. The breaker is rated for a current of 70 amperes (A), making it suitable for applications requiring moderate current protection. It operates at a maximum voltage of 600 volts alternating current (Vac) and 250 volts direct current (Vdc), which accommodates a wide range of electrical environments.

The HFD3070's trip mechanism is designed to respond to both thermal and magnetic overload conditions. The fixed thermal trip component reacts to prolonged overcurrent conditions by utilizing a bimetallic element that bends when heated. This bending motion triggers the breaker to open the circuit, thereby providing protection against sustained overcurrent. The fixed magnetic trip, on the other hand, responds to short-circuit conditions. It operates on the principle of electromagnetic induction, where a sudden surge in current generates a magnetic field that activates the trip mechanism.
