HFD3225BP10 | Eaton F-frame Molded Case Circuit Breaker
- Regular price
- $1,566.00
- Sale price
- $1,566.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HFD3225BP10
Description
The HFD3225BP10 is part of Eaton’s Series C F‑Frame line of molded case circuit breakers—compact, high-reliability solutions designed for low-voltage power protection in industrial and commercial systems.
Technical Specifications
| Condition | New/Never Used Surplus |
|---|---|
| Brand | Eaton |
| Category |
Circuit Breaker
|
| Part Number | HFD3225BP10 |
| Subcategory | Molded Case Circuit Breaker |
| Amperage Rating |
225 A |
| Voltage Rating | 600 VAC, 250 VDC |
| Trip Type |
T186
|
| Circuit Breaker Type |
HFD
|
| Circuit Breaker Frame Type | Complete breaker |
| Series | Series C |
| Terminals | Load side |
| Frame | F |
| Frequency Rating |
50 to 60 Hz
|
| Interrupt Rating | 65 kAIC at 480 Vac 100 kAIC at 240 Vac |
| Number of Poles |
Three-pole
|
| Length/Depth | 3.38 in |
| Height | 4.13 in |
| Width | 4.1 in |
| Weight | 4.05 lbs |
Information About HFD3225BP10
The HFD3225BP10 is part of Eaton’s Series C F-frame molded case circuit breaker line—compact, high-performance solutions designed for dependable overcurrent protection in industrial and commercial low-voltage systems. This 3-pole, 225 A breaker features a fixed thermal-magnetic (LI) trip unit and supports up to 600 VAC and 250 VDC operation. With interrupt ratings up to 100 kA at 240 VAC and 65 kA at 480 VAC, the HFD3225BP10 delivers robust protection in panelboards, switchgear, and motor control applications.
Key Features:
- 3-Pole, 225 A Protection: Ideal for three-phase distribution systems in industrial plants, OEM panels, and control centers.
- High Interrupting Capacity: Rated for 100 kA at 240 VAC, 65 kA at 480 VAC, and 25 kA at 600 VAC—ensuring safe and effective fault interruption.
- Thermal-Magnetic Trip Unit: Fixed long-time and instantaneous (LI) trip provides maintenance-free protection against overloads and short circuits.
- Bolt-On Mounting: Easily installs in panelboards and MCCs using standard load-side lugs and bolt-on connection points.
- AC/DC System Compatibility: Supports up to 600 VAC and 250 VDC, allowing versatile use across a variety of power systems.
- Compact F-Frame Design: Space-efficient footprint (~4.13″ × 4.13″ × 3.38″) optimizes enclosure space without compromising performance.
- UL & CSA Certified: Fully listed for global applications with IEC compatibility for international installations.
- Blow-Open Contacts: Patented contact design enhances breaking speed and arc suppression under high fault conditions.
- Reliable Construction: Designed with industrial-grade components to ensure long-term durability and consistent performance.
- Quick Availability: Frequently stocked by major suppliers and backed by Eaton’s limited warranty for confidence in mission-critical applications.
The Eaton HFD3225BP10 molded case circuit breaker delivers high interrupt capacity, versatile voltage support, and compact, bolt-on installation—making it a trusted choice for engineers, contractors, and OEMs seeking reliable circuit protection in modern power distribution systems.
