Product Description P/N: HGL36100

Description / Specifications

Description

The PowerPacT H-Frame circuit breakers are engineered to safeguard electrical systems from damage due to overloads and short circuits. Available with either thermal magnetic or Micrologic electronic trip protection units, this PowerPacT H-Frame circuit breaker delivers thermal magnetic circuit protection with a robust breaking capacity of 18kA at 600VAC.

All PowerPacT H-Frame circuit breakers feature dual-break rotating contacts, which effectively mitigate peak current during short circuit faults. They are equipped with an integral push-to-trip button integrated into the cover for manual circuit breaker tripping. These circuit breakers are offered in versatile 2 and 3-pole unit mount configurations, as well as I-Line constructions.






Technical Specifications

Part #

HGL36100

Category

Circuit Breaker

Subcategory

Molded Case Circuit Breaker

Line Rated Current

100 A

Number of Poles

3P

Protected Poles Description

3t

Control Type

Toggle

Breaking Capacity Code

G

[Ue] Rated Operational Voltage

690 V AC 50/60 Hz IEC 60947-3

Network Frequency

50/60 Hz

[Uimp] Rated Impulse Withstand Voltage

8 kV IEC 60947-2

Trip Unit Technology

Thermal-magnetic

Magnetic Tripping Current

1700 A

Magnetic Hold Current

900 A

Continuous Current Rating

80 %

[Ui] Rated Insulation Voltage

750 V IEC 60947-2

Suitability for Isolation

Yes IEC 60947-2

Utilisation Category

Category A

AWG Gauge

AWG 14...AWG 3/0 aluminium/copper

Local Signalling

Switched off (OFF) 1 trip indicator green)

Mounting Mode

Unit mount lug

Mounting Support

Lug

Terminal Identifier

AL150HD

Power Wire Stripping Length

0.63 in (16 mm)

Color

Black

Height

6.42 in (163 mm)

Width

4.09 in (104 mm)

Depth

3.39 in (86 mm)

Net Weight

4.85 lb(US) (2.2 kg)



Information About HGL36100


The HGL36100 Circuit Breaker from the PowerPacT H-Frame series is engineered to safeguard electrical systems against overload and short circuit conditions. Available with either thermal magnetic or Micrologic electronic trip protection units, this breaker ensures robust circuit protection. Featuring thermal magnetic technology, it offers a substantial breaking capacity of 18kA at 600VAC, essential for mitigating high fault currents effectively.

All PowerPacT H-Frame circuit breakers, including the HGL36100, incorporate dual-break rotating contacts that minimize peak current during short circuit faults, thereby enhancing operational safety. A built-in push-to-trip button on the cover allows manual tripping when required, facilitating quick response to electrical faults.

Designed for versatile installation, the PowerPacT H circuit breakers are adaptable for both unit mount and I-Line configurations in 2 and 3-pole setups. The HGL36100 specifically features lugs on both line and load sides, ensuring secure electrical connections.

This 3-pole circuit breaker is rated at 100A with a breaking capacity of 18kA at 600VAC, providing reliable performance in demanding applications. It maintains a continuous current rating of 80%, delivering consistent operation under load conditions.
