HI-1769-2WS | Allen Bradley Weigh Scale Module
HI-1769-2WS | Allen Bradley Weigh Scale Module
HI-1769-2WS | Allen Bradley Weigh Scale Module
    HI-1769-2WS | Allen Bradley Weigh Scale Module
HI-1769-2WS | Allen Bradley Weigh Scale Module

HI-1769-2WS | Allen Bradley Weigh Scale Module

Part #: HI-1769-2WS Manufactured by: Allen Bradley
Regular price
$4,389.00
Sale price
$4,389.00
Regular price
0 in Stock
Condition: New-Surplus Original Box
Shipping calculated at checkout.
Product Overview
The HI-1769-2WS weigh scale module delivers accurate and stable weight measurements for automation and control application...  Read more
We accept:
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Venmo
  • Visa
warranty
IQElectro 2-Year Warranty
Warranty for Product #: HI-1769-2WS
IQElectro offers a free 2-year warranty on all products. You can trust that every purchase is a reliable investment in the future of your company. Warranty Terms
2-3 Day Free Shipping
Packed Ready to Ship
24/7 Expert Support
Return within 30-Days
IQElectro LLC BBB Business Review
IQElectro is Not an authorized distributor for Allen Bradley
Original Manufacturer's Warranty Not Covered, This Product is SURPLUS.

Product Description P/N: HI-1769-2WS

Description / Specifications

Description

The Allen Bradley HI-1769-2WS Weigh Scale Module offers precise weight measurement for industrial applications. Designed for seamless integration, it supports up to two channels, allowing efficient monitoring of strain gauge load cells.



Technical Specifications

Condition New/Never Used Surplus
Brand Allen Bradley
Category Scales
Series CompactLogix
Part Number HI-1769-2WS
Subcategory Scale Boards & Controls
Power Provided from the backplane of the rack: +5Vdc
Backplane Current < 0.5 Amps at 5V DC
Inputs Signal, -0.3mV through +15.3 mV
No. of inputs Two (2) channels
Outputs Excitation 5Vdc





Information About HI-1769-2WS

The HI-1769-2WS is a dual-channel weigh scale module engineered for use with Allen Bradley systems. It accommodates up to eight 350 Ohm full Wheatstone bridge load sensors, ensuring accurate readings with 5V excitation. This module is ideal for vessel weighing applications, providing reliable input for process automation and material measurement.

Key Features:

  • Dual-Channel Support: The module can manage two independent weighing channels, allowing simultaneous measurements from different load cells.
  • High Sensor Capacity: It supports up to eight 350 Ohm full Wheatstone bridge strain gauge load sensors, providing accurate and reliable weight data.
  • Stable Excitation Voltage: The module supplies a consistent 5V excitation to the connected load cells, ensuring precise sensor performance.
  • Robust Power Ratings: The HI-1769-2WS operates at 5AMP for 5VDC and 0AMP for 24VDC, making it energy efficient and reliable for long-term use.

The HI-1769-2WS ensures dependable performance, making it a valuable addition to precision weighing systems. Its flexible design enhances operational efficiency across various industrial processes.
