HJA261502 | Square D 150A 2-Pole 600V Thermal Magnetic Molded Case Circuit Breaker
- Regular price
- $2,415.00
- Sale price
- $2,415.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HJA261502
Description
The Square D HJA261502 is a 2-pole thermal magnetic molded case circuit breaker rated for 150 amps at 600VAC/250VDC. Designed for dependable overload and short-circuit protection, it features an I-Line style plug-in connection for simplified installation. The breaker achieves high interrupting performance with ratings of 100kA at 240VAC, 65kA at 480VAC, and 25kA at 600VAC, ensuring safe and efficient power distribution in demanding applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Square D |
| Category | Circuit Protection |
| Part Number | HJA261502 |
| Subcategory | Molded Case Circuit Breaker |
| Series | PowerPact H |
| Type | Thermal Magnetic |
| Frame Type | H-Frame |
| Number of Poles | 2 |
| Rated Current | 150 A |
| Rated Voltage | 600 VAC / 250 VDC |
| Interrupting Rating | 100kA @ 240V, 65kA @ 480V, 25kA @ 600V |
| Trip Functions | Long Time, Instantaneous |
| Connection Type | I-Line Style Plug-In |
| Mounting Type | I-Line Bracket |
| Continuous Current Rating | 80% |
| Protection Type | Overload, Short Circuit |
| Wire Size | AWG 14–3/0 Cu/Al |
| Temperature Range | -25°C to +70°C |
| Standards Compliance | UL, CSA, IEC, NOM, CE, RoHS |
| Rated Impulse Voltage | 8 kV |
| Insulation Voltage | 750 V |
| Torque Rating | 123.9 lbf.in (AWG 8–3/0) |
| IP Protection | IP40 (Front Cover) |
| Dimensions (H x W x D) | 6.4 x 4.09 x 3.39 in |
| Weight | 4.9 lb (2.2 kg) |
Information About HJA261502
The HJA261502 is part of the Square D PowerPact H-Frame series, known for its compact design and robust protection capabilities. It utilizes a thermal-magnetic trip unit that combines long-time and instantaneous trip functions to safeguard circuits from both overload and short-circuit faults. This model is designed for I-Line panelboards and switchboards, allowing quick installation through its plug-on I-Line connection. Built to comply with UL, CSA, IEC, NOM, and CE standards, it ensures reliability across industrial, commercial, and institutional environments.
Key Features:
- Thermal-Magnetic Trip Unit: Provides precise long-time and instantaneous protection against overloads and faults.
- High Interrupting Capacity: Rated up to 100kA at 240VAC, 65kA at 480VAC, and 25kA at 600VAC for robust fault management.
- I-Line Plug-In Design: Enables fast, secure, and tool-free installation in I-Line panelboard systems.
- Compact H-Frame Construction: Offers high performance in a space-efficient molded case design.
- Durable Build: Meets IEC and UL standards for operation in harsh industrial and commercial environments.
- Wide Wire Range: Supports AWG 14 to 3/0 aluminum or copper conductors for flexible installation options.
- High Temperature Tolerance: Operates reliably from -25°C to +70°C, ensuring performance stability.
- Trip Indication: Includes an integrated visual trip indicator for simplified maintenance checks.
The HJA261502 delivers the reliability and precision required for industrial-grade circuit protection and safe electrical distribution.
