HJA36015 | Schneider Electric Circuit Breaker
- Regular price
- $950.00
- Sale price
- $950.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HJA36015
Description
The HJA36015 circuit breaker, part of Schneider Electric's PowerPacT H series, is a 15A, 3-pole device engineered to safeguard electrical systems from overloads and short circuits. It operates at 600VAC with a robust breaking capacity of 25kA, utilizing a thermal magnetic trip unit. Featuring an 80% continuous current rating, this breaker is configured with ABC phase connections and is suitable for I-Line mounting applications.
Technical Specifications
|
Part # |
HJA36015 |
|
Category |
Circuit Breaker |
|
Subcategory |
Molded Case Circuit Breaker |
|
Range |
PowerPact |
|
Product name |
PowerPact H |
|
Product or Component Type |
Circuit breaker |
|
Device Application |
Distribution Line |
|
Rated Current |
15 A |
|
Number of Poles |
3P |
|
Protected poles description |
3t |
|
Control Type |
Toggle |
|
Breaking Capacity Code |
J |
|
Rated Operational Voltage [Ue] |
690 V AC 50/60 Hz IEC 60947-3 |
|
Network Frequency |
50/60 Hz |
|
Rated Impulse Withstand Voltage [Uimp] |
8 kV IEC 60947-2 |
|
Trip Unit Technology |
Thermal-magnetic |
|
Magnetic Tripping Current |
750 A |
|
Magnetic Hold Current |
350 A |
|
Continuous Current Rating |
80 % |
|
Rated Insulation Voltage [Ui] |
750 V IEC 60947-2 |
|
Suitability for Isolation |
Yes IEC 60947-2 |
|
Utilisation Category |
Category A |
|
AWG Gauge |
AWG 14...AWG 3/0 aluminium/copper terminal |
|
Local Signalling |
Switched off (OFF) 1 trip indicator green) |
|
Mounting Mode |
I-Line bracket) |
|
Mounting Support |
Bracket |
|
Terminal Identifier |
AL150HD |
|
Mounting Height |
4.5 in (114.3 mm) |
Information About HJA36015
The HJA36015 circuit breaker, part of the PowerPacT H-Frame series by Eaton, is engineered to safeguard electrical systems from the detrimental effects of overloads and short circuits. Available with both thermal magnetic and Micrologic electronic trip protection options, this breaker ensures comprehensive protection tailored to various operational needs.
Specifically designed for demanding applications, the HJA36015 offers thermal magnetic circuit protection with a robust breaking capacity of 25kA at 600VAC, making it suitable for critical power distribution environments. Featuring dual-break rotating contacts, it effectively mitigates peak current during short circuit faults, enhancing system reliability and safety.
All PowerPacT H-Frame breakers include an integral push-to-trip button integrated into the cover, allowing for manual circuit interruption when necessary. Available in both 2-pole and 3-pole configurations, they support versatile unit mount and I-Line constructions. The I-Line variant facilitates straightforward installation and removal in I-Line applications, featuring I-Line terminations on the line side and mechanical lugs on the load side for secure connections.
