Product Description P/N: HLD3600F
Description
The HLD3600F is an Eaton Series C molded case circuit breaker frame. It is categorized under the L-frame series with a designation of HLD. This frame is equipped with a fixed thermal and fixed magnetic trip type mechanism. It is designed for three-pole (3P) configurations and has a current rating of 600 A. The voltage ratings are 600 Vac and 250 Vdc. The interrupting capacity is 100 kAIC at 240 Vac and 65 kAIC at 480 Vac, operating at a frequency of 50/60 Hz. The product is supplied as a frame only.
Technical Specifications
|
Part Number |
HLD3600F |
|
Manufacturer |
Eaton Cutler-Hammer |
|
Family |
Series C |
|
Pole |
3 |
|
Amp |
600 |
|
Volt |
600 |
|
Phase |
3 |
|
Category |
Molded Case / 3-Pole |
|
Connection |
Bolt On |
|
Type |
HLD |
|
Functions |
LI - Long-Time and Instantaneous |
|
Protection |
Thermal Magnetic |
|
AIC Ratings |
65kA@480V |
|
Frame Type |
L Frame |
Information About HLD3600F
The HLD3600F is an Eaton Series C molded case circuit breaker frame. This product belongs to the Series C family and is designated as an L-frame type. The circuit breaker frame is of the HLD type and is intended for frame-only applications. It features a fixed thermal and fixed magnetic trip type. The device is a three-pole configuration, capable of handling a current rating of 600 amperes.
The voltage rating for the HLD3600F is specified at 600 volts alternating current (VAC) and 250 volts direct current (VDC). The circuit breaker frame is designed to operate at a frequency of 50/60 Hz. It is engineered to provide protection against overcurrent conditions with thermal and magnetic trip functionalities.
The interrupting capacity of the HLD3600F is rated at 100 kiloamperes interrupting capacity (kAIC) at 240 VAC. At 480 VAC, the interrupting capacity is rated at 65 kAIC. This high interrupting capacity ensures the device can handle significant fault currents, thereby providing robust protection for electrical systems.
