HMCP015E0C | Eaton Cutler-Hammer Series C HMCP Motor Circuit Protector 15A 3-Pole 600V
- Regular price
- $415.00
- Sale price
- $415.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: HMCP015E0C
Description
The Eaton Cutler-Hammer HMCP015E0C is a molded case motor circuit protector designed for instantaneous short-circuit protection in three-phase motor circuits. This 3-pole device is rated at 15 A and operates at up to 600 V AC, using a magnetic-only trip mechanism.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton Cutler-Hammer |
| Category | Molded Case Circuit Breaker |
| Part Number | HMCP015E0C |
| Subcategory | Molded Case / 3-Pole |
| Series / Family | Series C |
| Breaker Type | HMCP |
| Frame Type | F Frame |
| Number of Poles | 3 |
| Amperage Rating | 15 A |
| Voltage Rating | 600 V AC / 250 V DC |
| Phase | 3 |
| Trip Unit Type | Magnetic Only |
| Protection Functions | I – Instantaneous |
| Interrupt Rating | 65 kA at 480 V |
| Connection Type | Feed-Thru |
| Application | Motor Circuit Protection |
Information About HMCP015E0C
The HMCP015E0C is part of Eaton’s Cutler-Hammer Series C lineup and is specifically engineered as a motor circuit protector. Unlike standard thermal-magnetic breakers, this HMCP device provides magnetic-only instantaneous protection, allowing it to respond rapidly to short-circuit conditions while relying on an external overload relay for thermal protection. Its three-pole configuration supports three-phase motor applications, and the F-frame construction provides mechanical robustness for industrial environments.
Key Features:
- HMCP Motor Circuit Protector Design: Intended for short-circuit protection in motor starter assemblies.
- Magnetic-Only Instantaneous Trip: Provides fast response to high-level fault currents without thermal delay.
- 15 Amp Rating: Suitable for lower-current three-phase motor circuits when coordinated with overload protection.
- Three-Pole Configuration: Supports three-phase electrical systems.
- High Interrupting Capacity: Rated at 65 kA for reliable fault interruption at 480 V.
- Feed-Thru Connection: Enables straightforward integration into motor control and distribution equipment.
- Series C Construction: Built for durability and compatibility within Eaton Cutler-Hammer systems.
The HMCP015E0C delivers the reliability and precision required for effective instantaneous motor circuit protection in Eaton Cutler-Hammer Series C motor control applications.
