HMCP070M2C | Eaton Cutler Hammer Series C 3-Pole 70A Magnetic Only Molded Case Circuit Breaker Feed-Thru
- Regular price
- $707.00
- Sale price
- $707.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HMCP070M2C
Description
The Eaton Cutler Hammer HMCP070M2C is a three-pole molded case circuit breaker designed for instantaneous short-circuit protection in three-phase motor circuits. It uses a magnetic-only trip mechanism with feed-thru connections and non-interchangeable trip settings for motor circuit protection applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Eaton |
| Category | Circuit Breaker |
| Part Number | HMCP070M2C |
| Subcategory | Molded Case Circuit Breaker |
| Family | Series C |
| Type | HMCP |
| Frame Type | F Frame |
| Rated Current | 70 A |
| Number of Poles | 3 |
| Phase | Three-phase |
| Protection Type | Magnetic Only |
| Trip Functions | Instantaneous (I) |
| Interrupt Rating | 65 kA at 480 V |
| Connection Type | Feed-Thru |
| Terminal Configuration | Line and Load Side Lugs |
| Application | Motor Circuit Protector |
| Motor FLA Range | 16.1–59.1 A |
Information About HMCP070M2C
The HMCP070M2C is part of the Eaton Cutler Hammer Series C product line, engineered specifically for motor circuit protection in industrial power systems. It features a compact molded case design with an F-frame construction that provides mechanical strength and stable mounting within motor control centers. The magnetic-only trip unit is factory set and non-interchangeable, delivering instantaneous response to short-circuit conditions without thermal overload functionality. This breaker is typically installed in applications where motor overload protection is provided separately by a dedicated overload relay.
Key Features
- Three-pole motor circuit protector: Provides simultaneous disconnection of all three phases to protect three-phase motor circuits during fault conditions.
- 70 amp current rating: Supports motor protection applications within the specified full-load ampere operating range.
- Magnetic-only protection mechanism: Responds instantly to short-circuit and high fault currents without time delay from thermal elements.
- Instantaneous trip function: Minimizes equipment damage by rapidly clearing severe electrical faults.
- High interrupting capacity: Rated at 65 kA at 480 V, allowing safe interruption of high available fault currents.
- Feed-thru connection design: Enables efficient wiring layouts by allowing conductors to pass directly through the breaker.
- Non-interchangeable trip unit: Ensures fixed protection characteristics for consistent coordination with motor starters and overload devices.
- Line and load side lug terminals: Allows direct conductor termination for secure and straightforward field installation.
The HMCP070M2C delivers the reliability and precision required for instantaneous short-circuit protection in demanding three-phase motor control and industrial power distribution systems.
