HOM2175BB | Schneider Electric | Miniature circuit-breaker

Description

Technical Specifications

Specifications

Information About HOM2175BB

Homeline miniature circuit breakers, like the HOM2175BB, are meticulously engineered and crafted to facilitate rapid installation and offer superior circuit protection. Specifically designed to seamlessly integrate with Homeline load centers, these circuit breakers ensure robust circuit protection within electrical systems.

The HOM2175BB miniature circuit breaker delivers standard circuit protection and bears the esteemed HACR rating. It functions as a 2-pole circuit breaker with plug-in mounting, accommodating a current rating of 175A at 120/240VAC. With a breaking capacity of 10kA AIR, it effectively mitigates electrical faults and ensures operational safety.

Electrical connections for the HOM2175BB are facilitated via box lugs, capable of accommodating 1 wires. These box lugs offer compatibility with wire sizes ranging from 4 AWG to 300 kcmil, supporting both copper and aluminum wires. The dimensions of the circuit breaker measure at 5.39 inches in height, 3.98 inches in width, and 3.13 inches in depth, ensuring a compact footprint within electrical enclosures.

Manufacturer information

Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
