HOMT2020250 | Schneider Electric Tandem Circuit Breaker
- Regular price
- $59.00
- Sale price
- $59.00
- Regular price
-
Couldn't load pickup availability
Do you need help?
Product Description P/N: HOMT2020250
Description
Homeline miniature circuit breakers are engineered for rapid installation and superior circuit protection within Homeline load centers. The HOMT202025 circuit breaker is a quad tandem configuration, occupying two HOM pole spaces. This arrangement includes a central two-pole breaker flanked by single-pole breakers on each side. The quad tandem breaker provides standard circuit protection and is HACR rated.
The two-pole breaker within this quad tandem setup is rated at 50A for 120/240VAC, while each single-pole breaker is rated at 20A for 120/240VAC. The circuit breaker offers a 10kA breaking capacity. The two-pole section accommodates wire sizes ranging from 14 AWG to 6 AWG for copper and 12 AWG to 6 AWG for aluminum. The single-pole sections accept wire sizes from 14 AWG to 8 AWG for both copper and aluminum conductors.
Technical Specifications
|
Part # |
HOMT2020250 |
|
Category |
Circuit Breaker |
|
Subcategory |
Panel Mount Circuit Breaker |
|
Product |
Miniature circuit-breaker |
|
Range |
Homeline |
|
Current Rating |
20 A (1P), 50 A (2P) |
|
Certifications |
UL Listed |
|
Voltage Rating |
120/240 V AC |
|
Mounting Type |
Plug-in |
|
Number of Poles |
1P (single pole), 2P (double pole) |
|
Short Circuit Current Rating |
10 kA |
|
Number of Spaces |
2 |
|
Circuit Breaker Type |
Quad tandem |
Information About HOMT2020250
The HOMT202025 tandem circuit breaker from the Homeline series by Square D™ is engineered to provide efficient circuit protection with a focus on rapid installation. Designed specifically for integration into Homeline load centers, this quad tandem breaker combines multiple circuit protection units within a compact form factor, utilizing two HOM pole spaces.
Comprising a central two-pole breaker flanked by two single-pole breakers, the HOMT202025 offers standard circuit protection capabilities. The two-pole breaker is rated at 50A for both 120VAC and 240VAC applications, while each single-pole breaker is rated at 20A for similar voltage requirements. With a maximum short-circuit current rating of 10 kA, this breaker ensures reliable performance under varying load conditions.
Electrical wiring compatibility includes the acceptance of 14 AWG to 6 AWG copper or 12 AWG to 6 AWG aluminum wires for the two-pole breaker, and 14 AWG to 8 AWG copper or aluminum wires for the single-pole breakers, facilitating versatile installation options.
Manufacturer information
Schneider Electric, a global leader in energy management and automation, offers innovative solutions for efficiency and sustainability. With a diverse portfolio spanning power distribution, automation, and renewable energy, Schneider Electric is committed to shaping a more connected and sustainable future.
