2001-400-090-126-280-20-100000-1-0-00 | Honeywell Absolute Pressure Transmitter 0–70 Bar
- Regular price
- $4,332.00
- Sale price
- $4,332.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: 2001-400-090-126-280-20-100000-1-0-00
Description
The Honeywell 2001-400-090-126-280-20-100000-1-0-00 is an absolute pressure transmitter designed for high-accuracy pressure measurement in demanding industrial environments. It provides stable analog output signals and robust stainless steel construction for long-term, reliable operation.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | Sensors |
| Part Number | 2001-400-090-126-280-20-100000-1-0-00 |
| Subcategory | Pressure Transmitters |
| Measurement Type | Absolute Pressure |
| Pressure Range | 0 to 70 bar (0 to 1000 PSI) |
| Output Signal | 4–20 mA (2-wire), 0–10 V (3-wire) |
| Accuracy | ±0.05% FS (BFSL) |
| Supply Voltage | 10–30 VDC (4–20 mA), 12–30 VDC (0–10 V) |
| Operating Temperature Range | -40 °C to +125 °C |
| Compensated Temperature Range | -20 °C to +80 °C |
| Response Time | < 1 ms |
| Long-Term Stability | ±0.1% FS per year |
| Overpressure Capability | 2 × Full Scale |
| Burst Pressure | 3 × Full Scale |
| Pressure Port | G 1/4" Male (EN 837) |
| Electrical Connection | M12 x 1, 4-pin Connector |
| Housing Material | 316L Stainless Steel |
| Ingress Protection | IP67 |
| Vibration Resistance | 10 g (20–2000 Hz) |
| Shock Resistance | 100 g (11 ms, half-sine) |
| Certifications | CE, RoHS |
| Weight | 0.47 kg |
Information About 2001-400-090-126-280-20-100000-1-0-00
The 2001-400-090-126-280-20-100000-1-0-00 is part of Honeywell’s precision pressure sensing portfolio, engineered for accurate absolute pressure measurement in industrial and process control applications. It features a rugged 316L stainless steel housing that supports operation in harsh mechanical and environmental conditions. The transmitter offers both current and voltage output options, enabling flexible integration with a wide range of control and monitoring systems. High accuracy, fast response time, and long-term stability make it suitable for applications requiring consistent and repeatable pressure data.
Key Features
- High-Accuracy Absolute Pressure Measurement: Delivers ±0.05% full-scale accuracy (BFSL) for precise pressure monitoring in critical processes.
- Dual Output Signal Capability: Supports both 4–20 mA and 0–10 V outputs, allowing flexible integration with different control architectures.
- Wide Temperature Operating Range: Designed to operate reliably from -40 °C to +125 °C in demanding industrial environments.
- Rugged Stainless Steel Construction: 316L stainless steel housing provides excellent resistance to corrosion, vibration, and mechanical stress.
- Fast Dynamic Response: Response time under 1 ms enables accurate capture of rapid pressure changes.
- High Overpressure Tolerance: Rated for up to 2× full-scale overpressure and 3× burst pressure for enhanced system safety.
- Industrial Protection and Compliance: IP67-rated enclosure with CE and RoHS compliance supports use in regulated industrial installations.
The 2001-400-090-126-280-20-100000-1-0-00 delivers the reliability and precision required for absolute pressure measurement in industrial automation and process control systems.
