CQM1H-CTB41 | Honeywell High-Speed Counter Board with 4 Pulse Inputs
- Regular price
- $534.00
- Sale price
- $534.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: CQM1H-CTB41
Description
The Honeywell CQM1H-CTB41 is a high-speed counter board designed to process fast pulse input signals in industrial automation systems. It supports both single-phase and quadrature counting modes, enabling accurate measurement of position, speed, and motion-related data. This board is typically used in applications such as encoders, conveyors, and high-speed inspection equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | PLC Accessories |
| Part Number | CQM1H-CTB41 |
| Subcategory | High-Speed Counter Boards |
| Counter Type | High-speed pulse counter |
| Pulse Input Channels | 4 |
| Single-Phase Input Frequency | 50 kHz / 500 kHz |
| Quadrature Input Frequency | 25 kHz / 250 kHz |
| Output Type | Transistor outputs |
| Number of Outputs | 4 |
| Output Response Time | 1 ms |
| Maximum Boards per CPU | Up to 2 |
| Mounting Type | PLC expansion board |
| Application | Encoder and pulse signal processing |
| Weight | Approx. 0.3 kg |
Information About CQM1H-CTB41
The CQM1H-CTB41 is a high-speed counter expansion board engineered for use with compatible Honeywell PLC CPUs. It provides multiple pulse input channels and transistor outputs to support precise counting and fast control responses. The board is designed to handle high-frequency signals, making it suitable for demanding motion and feedback applications. Its architecture allows up to two units per CPU, enabling scalable system designs without sacrificing performance.
Key Features:
- Four Pulse Input Ports: Supports multiple high-speed input signals for simultaneous counting tasks.
- High-Frequency Single-Phase Counting: Handles 50 kHz or 500 kHz pulse inputs in single-phase mode.
- Quadrature Input Support: Processes 25 kHz or 250 kHz quadrature signals for direction-sensitive counting.
- Four Transistor Outputs: Provides fast output response with 1 ms operation time.
- High-Speed Counter Functionality: Designed for accurate position, speed, and event counting.
- CPU Expandability: Supports installation of up to two boards per compatible CPU.
The CQM1H-CTB41 delivers the reliability and precision required for high-speed counting and motion-related industrial control applications.
