Honeywell HPFF8CME 8A 24VDC Fire Alarm NAC Expander Power Supply Chassis
- Regular price
- $607.00
- Sale price
- $607.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: HPFF8CME
Description
The Honeywell HPFF8CME is an 8 A, 24 VDC Notification Appliance Circuit (NAC) expander and power supply chassis designed to increase available notification power in compatible fire alarm systems. This export configuration operates from 240 VAC at 50 Hz and provides four supervised NAC outputs plus auxiliary DC power for connected life-safety equipment.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | Fire Alarm Systems |
| Part Number | HPFF8CME |
| Subcategory | NAC Expander Power Supplies |
| Product Series | HPFF8 Series |
| Product Type | NAC Expander / Power Supply Chassis |
| Mounting Configuration | Chassis Mount |
| Primary Input Power | 240 VAC, 50 Hz |
| Primary Input Current | 2.1 A |
| Output Voltage | 24 VDC, Regulated and Filtered |
| Maximum Total Output | 8.0 A |
| NAC Outputs | 4 |
| Maximum NAC Output | 3.0 A per Circuit |
| Auxiliary Output | Up to 2.0 A |
| NAC Configuration | Class A and/or Class B |
| Battery Charging Capacity | 7–26 Ah |
| Control Input Compatibility | 12 VDC or 24 VDC |
| Operating Temperature | 32°F to 120°F (0°C to 49°C) |
| Relative Humidity | 10%–93%, Non-Condensing |
| Weight | Approx. 16 lb |
Information About HPFF8CME
The HPFF8CME is a Honeywell HPFF8 Series chassis-mounted NAC expander configured specifically for export installations requiring 240 VAC, 50 Hz input power. Its regulated and filtered 24 VDC architecture provides four notification circuits that can be arranged as four Class B circuits, two Class A circuits, or a combination of Class A and Class B outputs. The unit includes two independent supervised control inputs, integral battery charging, NAC fault supervision, ground-fault monitoring, AC-fail indication, and trouble relay contacts. As a chassis model, it is designed for installation in a compatible large equipment enclosure, where multiple power-supply chassis can be installed when additional system capacity is required.
Key Features:
- 8 A Total Capacity: Provides up to 8.0 A combined output for notification and auxiliary fire alarm loads.
- Regulated 24 VDC Output: Supplies filtered and regulated 24 VDC power for compatible notification appliances and auxiliary devices.
- Four NAC Outputs: Provides four supervised notification appliance circuits rated up to 3.0 A individually within the 8.0 A total limit.
- Flexible Circuit Classes: Supports four Class B, two Class A, or two Class B plus one Class A configuration without an additional adapter.
- Export Power Configuration: HPFF8CME operates from a 240 VAC, 50 Hz primary power source.
- Supervised Battery Charger: Supports lead-acid standby batteries from 7 Ah through 26 Ah.
- Dual Control Inputs: Incorporates two independent optically isolated supervised input/control circuits compatible with 12 or 24 VDC panels.
- Fault Monitoring: Provides NAC overload protection, battery supervision, ground-fault detection, AC-fail monitoring, and diagnostic status LEDs.
The HPFF8CME delivers the reliability and precision required for expanding notification appliance power and supervised auxiliary power in fire alarm systems.
