Honeywell M7284Q1082 Modutrol IV 150 lb-in Non-Spring Return Motor
- Regular price
- $1,599.00
- Sale price
- $1,599.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: M7284Q1082
Description
The Honeywell M7284Q1082 is a Modutrol IV motor designed for modulating control of HVAC dampers and valves. It provides 150 lb-in of torque, a 90-degree stroke, 4-20 mA control, and non-spring-return operation for compatible HVAC applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | HVAC |
| Part Number | M7284Q1082 |
| Subcategory | HVAC Actuators |
| Product Type | Modutrol IV Motor |
| Actuator Type | Non-Spring Return |
| Control Signal | Modulating, 4-20 mA |
| Power Supply | 24 VAC / 120 VAC / 230 VAC |
| Torque | 150 lb-in / 17 Nm |
| Stroke | 90° |
| Timing | 30 seconds nominal |
| Auxiliary Switches | 2 internal |
| Mounting | Foot Mounted |
| Connection | Screw Terminals |
| Weight | 7.48 lbs |
Information About M7284Q1082
The M7284Q1082 is a Honeywell Modutrol IV motor with a foot-mounted construction for installation in HVAC control systems. It operates with 24, 120, or 230 VAC power and uses a modulating 4-20 mA control signal. The motor includes two internal auxiliary switches and provides a nominal 30-second timing for its 90-degree stroke. It is specified as a replacement for the Honeywell M7284Q1033 and is designed for applications requiring 150 lb-in of actuator torque.
Key Features:
- Modutrol IV Motor: Honeywell actuator designed for HVAC damper and valve control applications.
- Non-Spring Return: Operates without a spring-return mechanism for standard modulating control.
- Torque Rating: Provides 150 lb-in (17 Nm) of rated torque.
- Control Signal: Supports modulating 4-20 mA control input.
- Stroke: Provides a 90-degree nominal operating stroke.
- Auxiliary Switches: Includes two internal auxiliary switches for control and switching functions.
- Timing: Provides a 30-second nominal timing for the specified stroke.
- Power Supply: Supports 24 VAC, 120 VAC, and 230 VAC operation.
The M7284Q1082 delivers the reliability and precision required for modulating HVAC damper and valve control applications.
