NA5-15W101B-V1 | Honeywell 15.4-Inch Touch Screen HMI with WXGA Display
- Regular price
- $4,287.00
- Sale price
- $4,287.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: NA5-15W101B-V1
Description
The Honeywell NA5-15W101B-V1 is a 15.4-inch touchscreen HMI designed for advanced visualization and operator control in industrial automation systems. It features a high-resolution TFT display capable of rendering detailed graphics and process data with clarity. This HMI is suited for machine control, production monitoring, and complex operator interface applications.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | Human Machine Interface |
| Part Number | NA5-15W101B-V1 |
| Subcategory | Touch Screen HMI |
| Display Type | TFT |
| Screen Size | 15.4 inches |
| Resolution | 1280 × 800 pixels |
| Display Colors | 16,777,216 colors |
| Frame Color | Black |
| Ethernet Ports | 2 |
| USB Ports | 3 |
| RS-232 Ports | 1 |
| Front Protection Rating | IP65 |
| Front Width | 420 mm |
| Front Height | 291 mm |
| Panel Cutout Width | 391 mm |
| Panel Cutout Height | 267 mm |
| Built-in Depth | 63.1 mm |
| Weight | Approx. 3.2 kg |
Information About NA5-15W101B-V1
The NA5-15W101B-V1 is part of Honeywell’s NA series of touch screen HMIs developed for high-performance industrial environments. It is constructed with a durable black frame and an IP65-rated front panel to withstand dust and water exposure on the factory floor. The unit supports multiple communication interfaces, including Ethernet, USB, and serial connectivity, enabling flexible integration with PLCs and automation networks. Its wide display and high color depth allow operators to manage detailed screens, alarms, and diagnostics efficiently.
Key Features:
- 15.4-Inch Wide TFT Display: Provides a large viewing area for detailed machine and process visualization.
- WXGA Resolution (1280 × 800): Delivers sharp graphics and clear text for complex HMI screens.
- High Color Depth: Supports up to 16,777,216 colors for accurate and detailed visual representation.
- Multi-Port Ethernet Connectivity: Equipped with two Ethernet ports for network flexibility and redundancy.
- Versatile USB Support: Includes three USB ports for peripherals, data transfer, and expansion.
- Industrial Protection Rating: IP65-rated front panel for reliable operation in harsh environments.
- Panel-Mount Design: Engineered for secure installation in control panels and enclosures.
The NA5-15W101B-V1 delivers the reliability and precision required for advanced operator interface and industrial control applications.
