Honeywell R7847C1005 Dynamic Self-Check Flame Amplifier Module
- Regular price
- $825.00
- Sale price
- $825.00
- Regular price
-
Couldn't load pickup availability
Product Description P/N: R7847C1005
Description
The Honeywell R7847C1005 is a 7800 Series flame amplifier designed for use with Honeywell burner-management relay modules. It is a dynamic self-check amplifier intended for C7012E and C7012F ultraviolet flame detectors and provides a 2β3 second flame-failure response time.
Technical Specifications
| Condition | New/Never Used Surplus |
| Brand | Honeywell |
| Category | HVAC & Burner Controls |
| Part Number | R7847C1005 |
| Subcategory | Flame Amplifiers |
| Device Type | Dynamic Self-Check Flame Amplifier |
| Series | 7800 |
| Flame Detection | Ultraviolet |
| Compatible Flame Detector | C7012E, C7012F |
| Flame Failure Response Time | 2.0β3.0 seconds |
| Self-Checking | Dynamic Self-Check |
| Compatible Controls | Honeywell 7800 Series Relay Modules |
| Mounting | Plug-In PCB Edge Connector |
| Color Identification | Green |
| Approvals | UL, CSA, Factory Mutual |
| Country of Origin | Mexico |
| External Sensor Power | 20 VDC Β±10%, 75 mA max. |
| Operating Temperature | 32Β°F to 122Β°F / 0Β°C to 50Β°C |
| Relative Humidity | 5β95% RH, non-condensing |
| Mounting | Panel / DIN Rail / Field |
| Status Indicator | LED |
| Weight | 0.185 lb |
Information About R7847C1005
The R7847C1005 is a plug-in flame amplifier for Honeywell 7800 Series primary safety controls. It uses dynamic self-check technology to monitor the flame-detection system and is specifically matched with C7012E/F ultraviolet flame detectors. Honeywell documentation identifies a 2.0β3.0 second flame-failure response time for this amplifier. The module is designed to be installed in the compatible relay module through a keyed printed-circuit-board edge connector.
Key Features:
- Flame Amplifier: Provides flame-signal processing for Honeywell 7800 Series burner controls.
- Dynamic Self-Check: Continuously checks the flame-detection system and amplifier operation.
- UV Detector Compatibility: Designed for use with C7012E and C7012F ultraviolet flame detectors.
- 2β3 Second FFRT: Provides a specified flame-failure response time of approximately 2β3 seconds.
- Plug-In Design: Installs directly into compatible Honeywell relay modules.
- Keyed Connector: Uses a keyed PCB edge connector to help ensure correct installation.
- Diagnostic Monitoring: Supports flame-signal monitoring through the compatible burner-control system.
- Green Identification: Honeywell documentation identifies the dynamic self-check amplifier with green color coding.
The R7847C1005 provides the flame-signal amplification and dynamic monitoring required for compatible Honeywell burner-management systems.
